Specifications
Scanning Modes
Scanning Area
Resolution
Interface
Dimensions (L x W x H)
Net Weight
Voltage
Power Consumption
Environment
Power supply
(AC/DC adapter)
System Requirements
General requirements
• CD-ROM drive (for installing software)
• Color display with 24-bit color output capability
• 128MB RAM (256MB recommended)
PC and compatibles
• Pentium III PC or higher with USB or Hi-Speed USB (USB 2.0)
• Microsoft Windows 98SE, Me, 2000, XP or Vista
Macintosh
• iMac or Mac G3/G4/G5 with built-in USB port
• Mac OS X 10.3 or later
Important
Specifications, software bundles, and accessories are subject to change without
notice. Not responsible for typographic errors.
Color, grayscale, and black-and-white in a single
scanning pass
True 48-bit color (approx. 281 billion colors)
16-bit grayscale (approx. 65,535 shades of gray)
Reflective: 8.5" x 11.7" (216 mm x 297 mm)
Transparent: 5" x 10" (127 mm x 254 mm)
Optical: 4800 dpi x 9600 dpi (ScanMaker s480); 3200 dpi x
6400 dpi (ScanMaker s380)
Interpolated: 65,535 dpi (PC); 32,767 dpi (Mac)
Hi-Speed USB (USB 2.0)
17.99" x 9.76" x 2.24" (457 mm x 248 mm x 57 mm)
5.39 lbs (2.45 kg)
AC 100V to 120V (U.S. and Canada)
AC 200V to 240V (Europe and others)
50/60 Hz
15W (12V/1.25A)
Operating Temperature: 50° F to 104° F (10° C to 40° C)
Relative Humidity: 20% to 85%
Voltage Manufacturer
100V to 120V HARD
200V to 240V HARD
ScanMaker s480/s380 Supplement
Model No.
HDAD15W101-123
HDAD15W101-124
15
