Specifications / System Requirements - Microtek ScanMaker i800 Plus Supplement Manual

Specifications
Model Type
Image Sensor
Light Source
Scanning Modes
Scanning Area
Resolution
Dynamic Range
Interface
Dimensions (L x W x H)
Net Weight
Voltage
Power Consumption
Environment
Power supply
(AC/DC adapter)
System Requirements
General Requirements
• CD/DVD-ROM drive (for installing software)
• Color display with 24-bit color output capability
• 512 MB RAM or more
PC and compatibles
• Pentium IV PC or higher with Hi-Speed USB (USB 2.0) port
• Microsoft Windows XP, Vista or Windows 7
Macintosh
• iMac or Mac G3/G4/G5 with built-in USB port
• Mac OS X 10.4 or later
Important
Specifications, software bundles, and accessories are subject to change without
notice. Not responsible for typographic errors.
MRS-9600TFU2L
CCD (Charge-Coupled Device)
LED (Light Emitting Diode)
Color, grayscale, and black-and-white in a single scanning pass
True 48-bit color (approx. 281 x 10
16-bit grayscale (approx. 65,536 shades of gray)
Reflective: 8.5" x 14" (216 mm x 356 mm)
Transparent: 8" x 12" (203 mm x 305 mm)
Optical: 4800 dpi x 9600 dpi
Interpolated: 65,535 dpi (PC); 32,767 dpi (Mac)
4.0 Dmax
Hi-Speed USB (USB 2.0)
22.6" x 11.7" x 4.6" (576 mm x 297 mm x 118 mm)
14.1 lbs (6.4 kg)
AC 100V to 240V, 50/60 Hz (Input)
DC 15V, 2.5A (Output)
38 W (Max)
Operating Temperature: 50° F to 104° F (10° C to 40° C)
Relative Humidity: 20% to 85%
Voltage Manufacturer
100V to 240V WUXI HARD
ScanMaker i800 Plus Supplement
12
colors)
Model No.
HDAD38W101
29
