Specifications
Scanning Modes
Light Source
Scanning Area
Resolution
Optical Density
Interface
Dimensions (L x W x H) 24.7" x 14.8" x 5.1" ( 627.5 x 375.9 x 129.5 mm);
Weight
Voltage
Power Consumption
Environment
System Requirements
General Requirements
• DVD-ROM drive (for installing software)
• Color display with 24-bit color output capability
• 512 MB RAM or more
PC and compatibles
• Pentium IV PC or higher with Hi-Speed USB (USB 2.0) port
• Windows 7 / 8 / 10
Mac
• Intel-Based Mac computer with built-in USB port
• macOS 10.15 or later
Important
Specifications, software bundles, and accessories are subject to change without notice.
Not responsible for typographic errors.
Color, grayscale, and black-and-white in a single
scanning pass
True 48-bit color (approx. 281 billion colors)
16-bit grayscale (approx. 65,536 shades of gray)
LED
Reflective: 12" x 16.9" (304.8 mm x 429.26 mm)
Transparent: 12" x 16" (304.8 mm x 406.4 mm)
Optical: 3200 (H) dpi x 6400 (V) dpi
4.2 Dmax
Hi-Speed USB (USB 2.0)
24.7" x 14.8" x 7.1" ( 627.5 x 375.9 x 180.5 mm)
(with TMA 1600-III)
26.4 lbs / 12 kg;
35.4 lbs / 16.1 kg (with TMA 1600-III)
AC 100V-240V, 47-63 Hz, 1.5 A max.
54.9 W max.
Operating Temperature: 50° F to 104° F (10° C to 40° C)
Relative Humidity: 20% to 85%
ScanMaker 1000XL Plus User Guide 35
