From
Enclosure 1
Interconnect
Module 5/6 Port 5
Enclosure 1
Interconnect
Module 5/6 Port 6
Enclosure 1
Interconnect
Module 5/6 Port 7
Enclosure 1
Interconnect
Module 5/6 Port 8
D.1 1 One c7000 Enclosure with Double-Density Server Blades, the HP 4X
DDR InfiniBand Switch Module, and an External InfiniBand Switch
If the single c7000 enclosure configuration includes an external InfiniBand switch, the two HP
4X DDR InfiniBand switch modules are connected together through that switch. If the
configuration also includes an external control node, the InfiniBand HCA in the control node is
connected to Port 24 of the external InfiniBand switch.
From
IB 24 Port Switch
Port 1
IB 24 Port Switch
Port 2
IB 24 Port Switch
Port 3
IB 24 Port Switch
Port 4
IB 24 Port Switch
Port 5
IB 24 Port Switch
Port 6
IB 24 Port Switch
Port 7
IB 24 Port Switch
Port 8
IB 24 Port Switch
Port 9
IB 24 Port Switch
Port 10
IB 24 Port Switch
Port 11
IB 24 Port Switch
Port 12
D.11 One c7000 Enclosure with Double-Density Server Blades, the HP 4X DDR InfiniBand Switch Module, and an External
Label To
Enclosure 1 Interconnect
E1-IMB5-P5 Module 7/8 Port 5
Enclosure 1 Interconnect
E1-IMB5-P6 Module 7/8 Port 6
Enclosure 1 Interconnect
E1-IMB5-P7 Module 7/8 Port 7
Enclosure 1 Interconnect
Module 7/8 Port 8
E1-IMB5-P8
Control Node InfiniBand
HCA
Label To
Enclosure 1 Interconnect
IB-SW1-P1 Module 5/6 Port 1
Enclosure 1 Interconnect
IB-SW1-P2 Module 5/6 Port 2
Enclosure 1 Interconnect
IB-SW1-P3 Module 5/6 Port 3
Enclosure 1 Interconnect
IB-SW1-P4 Module 5/6 Port 4
Enclosure 1 Interconnect
IB-SW1-P5 Module 5/6 Port 5
Enclosure 1 Interconnect
IB-SW1-P6 Module 5/6 Port 6
Enclosure 1 Interconnect
IB-SW1-P7 Module 5/6 Port 7
Enclosure 1 Interconnect
IB-SW1-P8 Module 5/6 Port 8
Enclosure 1 Interconnect
IB-SW1-P9 Module 7/8 Port 1
Enclosure 1 Interconnect
IB-SW1-P10 Module 7/8 Port 2
Enclosure 1 Interconnect
IB-SW1-P11 Module 7/8 Port 3
Enclosure 1 Interconnect
IB-SW1-P12 Module 7/8 Port 4
Label Comment
E1-IMB7-P5
E1-IMB7-P6
E1-IMB7-P7
Not used if the control node is a
E1-IMB7-P8 rack-mount server connected to the
InfiniBand fabric
Only used if the control node is a
Control-P1 rack-mount server connected to the
InfiniBand fabric
Label Comment
E1-IMB5-P1
E1-IMB5-P2
E1-IMB5-P3
E1-IMB5-P4
E1-IMB5-P5
E1-IMB5-P6
E1-IMB5-P7
E1-IMB5-P8
E1-IMB7-P1
E1-IMB7-P2
E1-IMB7-P3
E1-IMB7-P4
91
InfiniBand Switch
