HP Cluster Platform Express v2010 Overview page 118

From
ProCurve 2848 Port 21
ProCurve 2848 Port 22
ProCurve 2848 Port 23
ProCurve 2848 Port 24
ProCurve 2848 Port 25
ProCurve 2848 Port 26
ProCurve 2848 Port 27
ProCurve 2848 Port 28
ProCurve 2848 Port 29
ProCurve 2848 Port 30
ProCurve 2848 Port 31
ProCurve 2848 Port 32
ProCurve 2848 Port 33
ProCurve 2848 Port 34
ProCurve 2848 Port 35
ProCurve 2848 Port 36
ProCurve 2848 Port 37
ProCurve 2848 Port 38
ProCurve 2848 Port 39
ProCurve 2848 Port 40
ProCurve 2848 Port 41
ProCurve 2848 Port 42
ProCurve 2848 Port 43
ProCurve 2848 Port 44
ProCurve 2848 Port 45
ProCurve 2848 Port 46
ProCurve 2848 Port 47
ProCurve 2848 Port 48
118 Cabling Tables for Rack-Mountable Servers
Label To
Admin-ES1-P21 Embedded NIC1 (eth0) in Node 17
Admin-ES1-P22 Embedded NIC1 (eth0) in Node 16
Not connected
Not connected
Admin-ES1-P25 Embedded NIC1 (eth0) in Node 15
Admin-ES1-P26 Embedded NIC1 (eth0) in Node 14
Admin-ES1-P27 Embedded NIC1 (eth0) in Node 13
Admin-ES1-P28 Embedded NIC1 (eth0) in Node 12
Admin-ES1-P29 Embedded NIC1 (eth0) in Node 11
Admin-ES1-P30 Embedded NIC1 (eth0) in Node 10
Admin-ES1-P31 Embedded NIC1 (eth0) in Node 09
Admin-ES1-P32 Embedded NIC1 (eth0) in Node 08
Admin-ES1-P33 Embedded NIC1 (eth0) in Node 07
Admin-ES1-P34 Embedded NIC1 (eth0) in Node 06
Not connected
Not connected
Admin-ES1-P37 Embedded NIC1 (eth0) in Node 05
Admin-ES1-P38 Embedded NIC1 (eth0) in Node 04
Admin-ES1-P39 Embedded NIC1 (eth0) in Node 03
Admin-ES1-P40 Embedded NIC1 (eth0) in Node 02
Admin-ES1-P41 Embedded NIC1 (eth0) in Node 01
Admin-ES1-P42 Embedded NIC1 (eth0) in Control
Node
Available
Available
Available
Admin-ES1-P46 InfiniBand switch #2 management
port (if present)
Admin-ES1-P47 InfiniBand switch #1 Management
port (if present)
Admin-ES1-P48 Uplink to console switch
Label Cable
Server17-NIC1 C7533A
Server16-NIC1 C7533A
Server15-NIC1 C7533A
Server14-NIC1 C7533A
Server13-NIC1 C7533A
Server12-NIC1 C7533A
Server11-NIC1 C7533A
Server10-NIC1 C7533A
Server09-NIC1 C7533A
Server08-NIC1 C7533A
Server07-NIC1 C7533A
Server06-NIC1 C7533A
Server05-NIC1 C7533A
Server04-NIC1 C7533A
Server03-NIC1 C7533A
Server02-NIC1 C7533A
Server01-NIC1 C7533A
Control-NIC1 C7533A
IB-SW2-NIC C7535A
IB-SW1-NIC C7535A
Consol-ES1-P50 C7533A
