Figure 1-4 42U Power Strip Installation
2
The following list describes the callouts shown in
1.
M5 screw attached to power strip.
2.
M5 screw attached to cable management bracket.
3.
Power strip mounting plate.
4.
Bracket attaching the power strip to the power strip mounting plate.
5.
Power strip mounting plate. Attach to right side of rack (looking in from the rear of the
rack).
6.
Mounting hole location on cable management plate.
7.
Seventh hole from right on mounting bracket.
8.
Third hole from right on mounting bracket.
9.
Insert pin in fifth hole from right on mounting bracket.
10. Insert pin in first hole from left on mounting bracket.
11. Hole mounting locations (viewed from the right side of the rack).
See the HP Cluster Platform Core Components Overview for more information.
1.4.4 Fast-Ethernet Network Switches and the Optional InfiniBand Network
Your HP Cluster Platform Express includes Fast–Ethernet switches and an optional InfiniBand
high-speed network.
Section 1.4.4.2
18
Cluster Platform Express Overview
3
1
4
5
Section 1.4.4.1
describes the components used for the optional InfiniBand network.
Figure
1-4:
describes the Fast-Ethernet network components, and
7
8
6
10
9
1 1
