A Port Labeling Syntax

This appendix provides the port labeling syntax for all of the cabling tables provided in this
document.
Table A-1
provides the wiring table syntax for CPE configurations.
Table A-1 Wiring Table Key
Label String
Admin
ESx
IB
SWx
Px
Ex
IMBx
OA
CONTROL
iLO
NICx
Examples
IB-SW1-P1
E2-IMB5-P2
CONTROL-IB-P1
Description
Identifies a component in the Admin network
Ethernet Switch number x
InfiniBand
Interconnect Switch number x (usually preceded with an interconnect identifier such as IB)
Port x on a component
c7000 Server Blade Enclosure Number
Enclosure Interconnect Module Bay Number
Enclosure Onboard Administrator
Control node
iLO or IPMI port
Ethernet port x
InfiniBand Switch 1 Port 1
c7000 Enclosure 2, Interconnect Module Bay 5, Port 2
Control node InfiniBand HCA port 1
61
