F Cabling Tables for Rack-Mountable Servers

This appendix provides the following cabling tables:
• Ethernet and Gigabit Ethernet network cabling tables for rack-mountable servers (see
Section F.1).
• InfiniBand cabling tables for rack-mountable servers (see

F.1 Ethernet and Gigabit Ethernet Network Cabling Tables

This section provides the console and administrative network cabling tables for rack-mountable
servers:
• In-band network switch console network for 24 nodes using the ProCurve 2824 Gigabit
Ethernet network switch (see
• In-band network switch administrative network for 1-20 nodes using the ProCurve 2824
Gigabit Ethernet switch (see
• In-band network switch administrative network for 21-32 nodes using the ProCurve 2848
Gigabit Ethernet switch (see
• In-band network switch administrative network for 1-20 nodes using the ProCurve 2626
Gigabit Ethernet switch (see
• In-band network switch administrative network for 21-32 nodes using the ProCurve 2650
Gigabit Ethernet switch (see
F.1.1 In-Band Network Switch Console Network for 24 Nodes Using the ProCurve
2824 Gigabit Ethernet Network Switch
The following table shows the in-band network switch console network for 24 nodes using the
ProCurve 2824 Gigabit Ethernet network switch:
From
ProCurve 2824 Port 1
ProCurve 2824 Port 2
ProCurve 2824 Port 3
ProCurve 2824 Port 4
ProCurve 2824 Port 5
ProCurve 2824 Port 6
ProCurve 2824 Port 7
ProCurve 2824 Port 8
ProCurve 2824 Port 9
ProCurve 2824 Port 10
ProCurve 2824 Port 11
ProCurve 2824 Port 12
Section F.1.1)
Section F.1.2)
Section F.1.3)
Section F.1.4)
Section F.1.5)
Label To
Admin-ES1-P1 Enclosure 1 Interconnect
Module 1 Port 21
Admin-ES1-P2 Enclosure 1 Interconnect
Module 1 Port 22
Admin-ES1-P3 Enclosure 1 Interconnect
Module 1 Port 23
Admin-ES1-P4 Enclosure 1 Interconnect
Module 1 Port 24
Not connected Not connected
Admin-ES1-P6 Enclosure 2 Interconnect
Module 1 Port 21
Admin-ES1-P7 Enclosure 2 Interconnect
Module 1 Port 22
Admin-ES1-P8 Enclosure 2 Interconnect
Module 1 Port 23
Admin-ES1-P9 Enclosure 2 Interconnect
Module 1 Port 24
Not connected Not connected
Not connected Not connected
Not connected Not connected
F.1 Ethernet and Gigabit Ethernet Network Cabling Tables
Section F.2).
Label Cable
E1-IMB1-P21
E1-IMB1-P22 Only present if
interconnect is GigE
E1-IMB1-P23 Only present if
interconnect is GigE
E1-IMB1-P24 Only present if
interconnect is GigE
Not connected
E2-IMB1-P21
E2-IMB1-P22 Only present if
interconnect is GigE
E2-IMB1-P23 Only present if
interconnect is GigE
E2-IMB1-P24 Only present if
interconnect is GigE
Not connected
Not connected
Not connected
115
