From
ProCurve 2650 Port 34
ProCurve 2650 Port 35
ProCurve 2650 Port 36
ProCurve 2650 Port 37
ProCurve 2650 Port 38
ProCurve 2650 Port 39
ProCurve 2650 Port 40
ProCurve 2650 Port 41
ProCurve 2650 Port 42
ProCurve 2650 Port 43
ProCurve 2650 Port 44
ProCurve 2650 Port 45
ProCurve 2650 Port 46
ProCurve 2650 Port 47
ProCurve 2650 Port 48
ProCurve 2650 Port 49
ProCurve 2650 Port 50

F.2 InfiniBand Cabling Tables for Rack-Mountable Servers

F.2.1 Cabling Topology and Rules

All of the cables in factory-integrated rack-mounted systems are labeled with their origin and
port destinations. You need to refer to the cabling tables only if you need to recable a dismantled
cluster using new, unlabeled cables.

F.2.1.1 Using the Cabling Tables

From the cabling tables listed in the appendices of this guide, select the appropriate cabling table
that matches the configuration of your cluster.
Verify the tables by comparing the port addresses in the tables to the port addresses printed on
the cable labels. These labels identify the origin and destination of each cable, such as from a
port in the interconnect, to a port in the HCA that is installed in the node.
Each cluster component, (interconnect chassis or cluster node) has a logical address defined by
its location in the cluster rack, and its position in the cluster topology. When two InfiniBand
interconnects are present in a configuration, switch 1 is on the bottom and switch 2 is immediately
above it. The HCA installed in a node's PCI bus has two ports, port 0 and port 1. For example,
the following table provides two sample origin and destination addresses:
Address
IB-SW1-P01
Server1-IB-P0
Label To
Consol-ES1-P34 Embedded MP in Node 06
Not connected
Not connected
Consol-ES1-P37 Embedded MP in Node 05
Consol-ES1-P38 Embedded MP in Node 04
Consol-ES1-P39 Embedded MP in Node 03
Consol-ES1-P40 Embedded MP in Node 02
Consol-ES1-P41 Embedded MP in Node 01
Consol-ES1-P42 Embedded MP in Control
Node
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Not connected
Consol-ES1-P50 Uplink to Admin switch
Routing Definition
Origin InfiniBand Switch 1, Port 01
Destination Server 1, InfiniBand HCA Port 0
Label
Server06-MP
Server05-MP
Server04-MP
Server03-MP
Server02-MP
Server01-MP
Control-MP
Admin-ES1-P48
F.2 InfiniBand Cabling Tables for Rack-Mountable Servers
Cable
C7533A
C7533A
C7533A
C7533A
C7533A
C7533A
C7533A
C7533A
