User's Manual
ECB-862 Series
Intel Pentium III Full-size PICMG CPU Card
with 4 USB 2.0, Audio, & Dual 10/100 Base-Tx Ethernet
rd
3
Ed. – 20 May, 2005
Part No.2047862000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECB-862 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intel ECB-862 Series

Summary of Contents for Intel ECB-862 Series

  • Page 1 User’s Manual ECB-862 Series Intel Pentium III Full-size PICMG CPU Card with 4 USB 2.0, Audio, & Dual 10/100 Base-Tx Ethernet Ed. – 20 May, 2005 Part No.2047862000...

  • Page 2: Fcc Statement

    ECB-862/862L FCC STATEMENT THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS "A"...

  • Page 3: Copyright Notice

    User’s Manual Copyright Notice Copyright © 2003 - 2005, Evalue Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.
  • Page 4 ECB-862/862L A Message to the Customer Evalue Customer Services Each and every Evalue’s product is built to the most exacting specifications to ensure reliable performance in the harsh and demanding conditions typical of industrial environments. Whether your new Evalue device is destined for the laboratory or the factory floor, you can be assured that your product will provide the reliability and ease of operation for which the name Evalue has come to be known.
  • Page 5 User’s Manual Product Warranty Evalue warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Evalue, or which have been subject to misuse, abuse, accident or improper installation.

  • Page 6: Packing List

    Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 ECB-862 Series Pentium III Full-size CPU card 1 Quick Installation Guide 1 CD-ROM contains the followings: — User’s Manual (this manual in PDF file) —...

  • Page 7: Table Of Contents

    User’s Manual MANUAL OBJECTIVES.....................1 INTRODUCTION ......................2 System Overview ....................2 System Specifications...................3 Architecture Overview...................5 2.3.1 VIA VT8602 North Bridge....................6 2.3.2 Advanced High-Performance DRAM Controller .............7 2.3.3 VIA VT82C686B South Bridge ..................8 2.3.4 Current PCI Bus Controller.....................9 2.3.5 IDE Interface (Bus Master Capability and Synchronous DMA Mode) ......10 2.3.6 USB ..........................10 2.3.7...
  • Page 8 ECB-862/862L 3.9.1 Audio / TV Output Connector (AUDIO1) ..............23 3.9.2 CD-ROM Audio Input Connector (CD1) ...............23 3.9.3 Primary IDE Connector (CN1) ..................24 3.9.4 Secondary IDE Connector (CN5) .................25 3.9.5 Signal Description – Primary & Secondary IDE Connector (CN1, CN5) ......26 3.9.6 Floppy Connector (CN2) ....................29 3.9.7...
  • Page 9 User’s Manual 4.5.10 Load Fail-Safe Defaults....................66 4.5.11 Load Optimized Defaults ....................67 4.5.12 Set Supervisor/User Password ..................67 4.5.13 Save & Exit Setup ......................67 4.5.14 Exit Without Saving ......................67 Flash BIOS Utility....................68 DRIVER INSTALLATION ..................69 Driver Installation for Ethernet Adapter............. 69 5.1.1 Windows 9x ........................69 Driver Installation for Display Adapter...............
  • Page 10 ECB-862/862L Memory Parity Error At......................95 Memory Size Has Changed Since Last Boot ................95 Memory Verify Error At......................95 Offending Address Not Found ....................95 Offending Segment ........................95 Press A Key To Reboot ......................96 Press F1 To Disable NMI, F2 To Reboot ..................96 RAM Parity Error –...

  • Page 11: Document Amendment History

    User’s Manual Document Amendment History Revision Date Comment October, 2003 Stephen Tsao Initial Release March, 2004 Stephen Tsao Add in 3.9.27 LCD panel connector description (page 37) May, 2005 Stephen Tsao 1. Modify CN19 USB pin definition 2. CN8’s signal updated. 3.

  • Page 12: Manual Objectives

    ECB-862/862L 1. Manual Objectives This manual describes in detail the Evalue Technology ECB-862 Single Board. We have tried to include as much information as possible but we have not duplicated information that is provided in the standard IBM Technical References, unless it proved to be necessary to aid in the understanding of this board.

  • Page 13: Introduction

    The ECB-862 is an all-in-one Full-size Pentium III Single Board Computer (SBC) designed with Intel embedded chipset VIA 8602 which supports the latest Intel Pentium III CPU with FSB up to 133 MHz, dual PCI-bus Fast Ethernet controllers, and M-Systems DiskOnChip socket.

  • Page 14: System Specifications

    ECB-862/862L System Specifications General Functions • CPU: Universal Socket 370 supports Intel FC-PGA/FC-PGA2 Pentium III / Celeron (CopperMine and Tualatin) and VIA C3 CPU with FSB up to 133MHz • CPU Socket: Intel FC-370, Socket 370 • BIOS: Award 2Mbit Flash BIOS •...

  • Page 15: Mechanical And Environmental

    User’s Manual Optional TV Output Interface TV Encoder: VIA VT1621 TV output interface: Supports both RCA jack and S terminal SSD Interface One 32-pin DIP socket supports M-Systems DiskOnChip 2000 series up to 1 G Bytes Compact Flash: One CF socket supports Type I / II Compact Flash Card Mechanical and Environmental •...

  • Page 16: Architecture Overview

    ECB-862/862L Architecture Overview The following block diagram shows the architecture and main components of ECB-862. The two key components on board are the VIA VT8602 North Bridge and VT82C686B super South Bridge. These two devices provide the ISA and PCI bus to which all the major components are attached.

  • Page 17: Via Vt8602 North Bridge

    User’s Manual 2.3.1 VIA VT8602 North Bridge The Apollo PLE133T Graphics Controller is a highly integrated display control device that incorporates a 64-bit 3D/2D graphic engine and video accelerator with advanced DVD video and optional TV output capability. It provides a flexible and high performance solution for graphics and video playback acceleration for various color depth and resolution modes.

  • Page 18: Advanced High-Performance Dram Controller

    ECB-862/862L 2.3.2 Advanced High-Performance DRAM Controller DRAM interface synchronous or pseudosynchronous with CPU FSB speed of 133 / 100 / 66 MHz DRAM interface may be faster than CPU by 33 MHz to allow use of PC133 with 100 MHz VIA C3, Pentium III or Pentium III-M (Tualatin) CPUs or use of PC100 with 66 MHz Celeron CPU DRAM interface may be slower than CPU by 33 MHz to allow use of older memory modules with a newer CPU...

  • Page 19: Via Vt82C686B South Bridge

    The VT82C686B PSIPC (PCI Super-I/O Integrated Peripheral Controller) is a high integration, high performance, power-efficient, and high compatibility device that supports Intel and non-Intel based processor to PCI bus bridge functionality to make a complete Microsoft PC99-compliant PCI/ISA system. In addition to complete ISA extension bus...

  • Page 20: Current Pci Bus Controller

    ECB-862/862L Integrated PCI-mastering dual full-duplex direct-sound AC97-link-compatible sound system. Hardware soundblaster-pro and hardware-assisted FM blocks are included for Windows DOS box and real-mode DOS compatibility. Loopback capability is also implemented for directing mixed audio streams into USB and 1394 speakers for high quality digital audio. Two game ports and one MIDI port ECP/EPP-capable parallel port Standard floppy disk drive interface...

  • Page 21: Ide Interface (Bus Master Capability And Synchronous Dma Mode)

    User’s Manual Supports L1/L2 write-back merged with PCI master post-write to minimize DRAM utilization Delay transaction from PCI master reading DRAM Read caching for PCI master reading DRAM Transaction timer for fair arbitration between PCI masters (granularity of two PCI clocks) Symmetric arbitration between Host/PCI bus for optimized system performance Complete steerable PCI interrupts...

  • Page 22: Ethernet

    2.3.8.2 Intel 82559ER Ethernet Controller (Optional) The 82559ER is part of Intel's second generation family of fully integrated 10BASE- T/100BASE-TX LAN solutions. The 82559ER consists of both the Media Access Controller (MAC) and the physical layer (PHY) combined into a single component solution. 82559 family members build on the basic functionality of the 82558 and contain power management enhancements.

  • Page 23: Compact Flash Interface

    User’s Manual 2.3.10 Compact Flash Interface A Compact Flash type II connector is connected to the secondary IDE controller. The Compact Flash storage card is IDE compatible. It is an ideal replacement for standard IDE hard drives. The solid-state design offers no seek errors even under extreme shock and vibration conditions.

  • Page 24: Hardware Configuration

    ECB-862/862L 3. Hardware Configuration This chapter explains you the instructions of how to set up your system. The additional information shows you how to install M-Systems’ DiskOnChip and program the Watchdog Timer. Installation Procedure 1. Turn off the power supply. 2.

  • Page 25: Socket 370 Processor

    User’s Manual Socket 370 Processor 3.3.1 Installing Pentium III / Celeron CPU Lift the handling lever of CPU socket outwards and upwards to the other end. Align the processor pins with pin holes on the socket. Make sure that the notched corner or dot mark (pin 1) of the CPU corresponds to the socket’s bevel end.

  • Page 26: M-Systems' Diskonchip Flash Disk

    ECB-862/862L M-Systems’ DiskOnChip Flash Disk ECB-862 reserves a 32-pin DIP socket to support M-Systems’ DiskOnChip flash disk up to 1 GB. The DiskOnChip is based on pure ISA bus and without PnP (Plug and Play) function. Before the installation, make sure that the DiskOnChip I/O address jumper is set properly to prevent the I/O resource conflict.

  • Page 27: Drivers Support

    User’s Manual 3.6.1 Drivers Support ECB-862 provides on CD-Title to support on-board VGA and Ethernet device drivers in various operating systems. Before installing the device drivers, please see the reference files in each sub-directory. You cannot install drivers from CD-Title directly. 16 ECB-862/862L User’s Manual...

  • Page 28: Jumper & Connector

    ECB-862/862L Jumper & Connector 3.7.1 Jumper & Connector Layout ECB-862/862L User’s Manual 17...

  • Page 29: Jumper & Connector List

    User’s Manual 3.7.2 Jumper & Connector List Connectors on the board are linked to external devices such as hard disk drives, keyboard, mouse, or floppy drives. In addition, the board has a number of jumpers that allow you to configure your system to suit your application. The following tables list the function of each of the board's jumpers and connectors.
  • Page 30 ECB-862/862L Connectors Label Function Note AUDIO1 Audio / TV output connector 8 x 2 box header, pitch 2.54mm CD-ROM audio input connector 4 x 1 wafer, pitch 2.0mm Primary IDE connector 20 x 2 box header, pitch 2.54mm Floppy connector 17 x 2 box header, pitch 2.54mm Power on connector 2 x 1 header, pitch 2.54mm...

  • Page 31: Setting Jumpers

    User’s Manual Setting Jumpers You can configure your board to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 32: External Speaker Select (Cn10)

    External speaker Onboard buzzer* CN10 * default 3.8.2 COM2 RS-232/422/485 Select (J2, J1) The ECB-862 series COM2 serial port can be selected as RS-232, RS-422, or RS-485 by setting J2 & J1. COM2 Select (J1, J2) RS-232* RS-422 RS-485 1 4 7 10...

  • Page 33: Clear Cmos (J3)

    User’s Manual 3.8.3 Clear CMOS (J3) You can use J3 to clear the CMOS data if necessary. To reset the CMOS data, set J3 to 2- 3 closed for just a few seconds, and then remove the jumper back to 1-2 closed. Clear CMOS (J3) Protect* Clear CMOS...

  • Page 34: Connector Definitions

    ECB-862/862L Connector Definitions 3.9.1 Audio / TV Output Connector (AUDIO1) Signal Signal Mic Bias AGND AGND Line-Out L Line-Out R SPK L SPK R Line-In L Line-In R AGND Yout Cout COMP 3.9.2 CD-ROM Audio Input Connector (CD1) Signal CD_GND CD_L CD_GND CD_R...

  • Page 35: Primary Ide Connector (Cn1)

    User’s Manual 3.9.3 Primary IDE Connector (CN1) Signal Signal RESET# PDD7 PDD8 PDD6 PDD9 PDD5 PDD10 PDD4 PDD11 PDD3 PDD12 PDD2 PDD13 PDD1 PDD14 PDD0 PDD15 PDDREQ PDIOW# PDIOR# PDIORDY IDESEL PDDACK# IRQ14 PDA1 CBLID PDA0 PDA2 PDDACT# 24 ECB-862/862L User’s Manual...

  • Page 36: Secondary Ide Connector (Cn5)

    ECB-862/862L 3.9.4 Secondary IDE Connector (CN5) Signal Signal RESET# SDD7 SDD8 SDD6 SDD9 SDD5 SDD10 SDD4 SDD11 SDD3 SDD12 SDD2 SDD13 SDD1 SDD14 SDD0 SDD15 SDDREQ SDIOW# SDIOR# SDIORDY IDESEL SDDACK# IRQ15 SDA1 CBLID SDA0 SDA2 SDDACT# ECB-862/862L User’s Manual 25...

  • Page 37: Signal Description - Primary & Secondary Ide Connector (Cn1, Cn5)

    User’s Manual 3.9.5 Signal Description – Primary & Secondary IDE Connector (CN1, CN5) PDA [2:0] Primary Disk Address [2:0]. These signals indicate which byte in either the ATA command block or control block is being addressed. If the IDE signals are configured for Primary and Secondary, these signals are connected to the corresponding signals on the Primary IDE connector.
  • Page 38 ECB-862/862L PDIOR# Primary Disk IO Read. In normal IDE this is the command to the IDE device that it may drive data onto the PDD [15:0] lines. Data is latched by PIIX4 on the negation edge of PDIOR#. The IDE device is selected either by the ATA register file chip selects (PDCS1#, PDCS3#) and the PDA [2:0] lines, or the IDE DMA slave arbitration signals (PDDACK#).
  • Page 39 User’s Manual PDIORDY Primary IO Channel Ready. In normal IDE mode, this input signal is directly driven by the corresponding IDE device IORDY signal. In an Ultra DMA/33 read cycle, this signal is used as STROBE, with the PIIX4 latching data on rising and falling edges of STROBE.

  • Page 40: Floppy Connector (Cn2)

    ECB-862/862L SDDACK# Secondary DMA Acknowledge. This signal directly drives the IDE device DMACK# signal. It is asserted by PIIX4 to indicate to IDE DMA slave devices that a given data transfer cycle (assertion of SDIOR# or SDIOW#) is a DMA data transfer cycle. This signal is used in conjunction with the PCI bus master IDE function.

  • Page 41: Signal Description - Floppy Connector (Cn2)

    User’s Manual 3.9.7 Signal Description – Floppy Connector (CN2) RDATA# The read data input signal from the FDD. Write data. This logic low open drain writes pre-compensation serial data to the selected FDD. An open drain output. Write enable. An open drain output. MOA# Motor A On.

  • Page 42: Parallel Port Connector (Cn6)

    ECB-862/862L 3.9.10 Parallel Port Connector (CN6) Signal Signal STB# AFD# ERR# INIT# SLIN# ACK# BUSY SLCT 3.9.11 Signal Description – Parallel Port Connector (CN6) PD [7:0] Parallel data bus from PC board to printer. The data lines are able to operate in PS/2 compatible bi-directional mode.

  • Page 43: Serial Port 2 Connector (Cn7)

    User’s Manual 3.9.12 Serial Port 2 Connector (CN7) Signal Signal 3.9.13 Serial Port 2 with External DB9 Connector (CN7) Signal Signal 3.9.14 HDD LED (CN8) SIGNAL HDLED +3.3V 3.9.15 Power Led & Key Lock Connector (CN11) Signal #LOCK PWLED 32 ECB-862/862L User’s Manual...

  • Page 44: System Fan Connector (Cn12)

    ECB-862/862L 3.9.16 System Fan Connector (CN12) SIGNAL +12V 3.9.17 Daughter Board Connector A (CN13) Signal Signal USBP4P B USBP3P B USBP4N B USBP3N B USBV4 USBV3 USBP2P B USBP1P B USBP2N B USBP1N B USBV2 USBV1 VCCSB SLED2 LLED2 ALED2 3.9.18 Auxiliary Power Connector (CN15) Signal...

  • Page 45: 10/100 Base-Tx Ethernet Connector (Cn16)

    User’s Manual 3.9.19 10/100 BASE-Tx Ethernet Connector (CN16) Signal TxD+ TxD- RxD+ RxD- 3.9.20 Signal Description – 10/100Base-Tx Ethernet Connector (CN16) TXD+ / TXD- Ethernet 10/100Base-Tx differential transmitter outputs. RXD+ / RXD- Ethernet 10/100Base-Tx differential receiver inputs. 3.9.21 IrDA Connector (CN17) Signal IRRX IRTX...

  • Page 46: Usb Connector (Cn19)

    ECB-862/862L 3.9.23 USB Connector (CN19) Signal CH1 CH2 Signal VCC1 VCC2 3.9.24 VGA Connector (CN20) Signal Signal ANA-GND ANA-GND GREEN DDCDAT ANA-GND BLUE HSYNC VSYNC DIG-GND DIG-GND DDCCLK 3.9.25 Signal Description – VGA Connector (CN20) HSYNC CRT horizontal synchronisation output. VSYNC CRT vertical synchronisation output.

  • Page 47: Lcd Panel Connector (Cn21)

    User’s Manual 3.9.26 LCD Panel Connector (CN21) Signal Signal ENBKL ENVEE SHFCLK VCON +3.3V +3.3V 36 ECB-862/862L User’s Manual...

  • Page 48: Lcd Panel Connector Description (Cn21)

    ECB-862/862L 3.9.27 LCD Panel Connector Description (CN21) 24-bit 18-bit 3.9.28 CPU Fan Connector (CN22) SIGNAL +12V ECB-862/862L User’s Manual 37...

  • Page 49: Lcd Inverter Connector (Cn23)

    User’s Manual 3.9.29 LCD Inverter Connector (CN23) Signal ENBKL +12V Note: For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VBR signal (pin 4) controlled by VR2. Please see the VR2 section for detailed circuitry information. 3.9.30 Internal Keyboard Connector (CN24) Signal...

  • Page 50: Lcd Contrast Adjustment Connector (Vr1)

    ECB-862/862L 3.9.32 LCD Contrast Adjustment Connector (VR1) Signal +3.3V VCON 3.9.33 LCD Backlight Brightness Adjustment Connector (VR2) Signal CN23 pin 4 Variation Resistor (Recommended: 4.7KΩ , >1/16W) ECB-862/862L User’s Manual 39...

  • Page 51: Award Bios Setup

    User’s Manual 4. Award BIOS Setup Starting Setup The AwardBIOS™ is immediately activated when you first power on the computer. The BIOS reads the system information contained in the CMOS and begins the process of checking out the system and configuring it. When it finishes, the BIOS will seek an operating system on one of the disks and then launch and turn control over to the operating system.

  • Page 52: Using Setup

    ECB-862/862L Using Setup In general, you use the arrow keys to highlight items, press <Enter> to select, use the PageUp and PageDown keys to change entries, press <F1> for help and press <Esc> to quit. The following table provides more detail about how to navigate in the Setup program using the keyboard.

  • Page 53: Getting Help

    User’s Manual Getting Help Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item. To exit the Help Window press <Esc> or the F1 key again. In Case of Problems If, after making and saving system changes with Setup, you discover that your computer no longer is able to boot, the AwardBIOS™...

  • Page 54: Setup Items

    ECB-862/862L 4.5.1 Setup Items The main menu includes the following main setup categories. Recall that some systems may not include all entries. 4.5.1.1 Standard CMOS Features Use this menu for basic system configuration. 4.5.1.2 Advanced BIOS Features Use this menu to set the Advanced Features available on your system. 4.5.1.3 Advanced Chipset Features Use this menu to change the values in the chipset registers and optimize your system's...

  • Page 55: Standard Cmos Setup

    User’s Manual 4.5.1.11 Save & Exit Setup Save CMOS value changes to CMOS and exit setup. 4.5.1.12 Exit Without Save Abandon all CMOS value changes and exit setup. 4.5.2 Standard CMOS Setup The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items.
  • Page 56 ECB-862/862L 4.5.2.1 Standard CMOS Selection This table shows the selections that you can make on the Standard CMOS Selection. Item Options Description Set the system date. Note that the ‘Day’ Date Month YYYY automatically changes when you set the date Time HH : MM : SS Set the system time...
  • Page 57 User’s Manual 4.5.2.2 IDE Adapters The IDE adapters control the hard disk drive. Use a separate sub menu to configure each hard disk drive. Figure 2 shows the IDE primary master sub menu. Use the legend keys to navigate through this menu and exit to the main menu. Use Table 3 to configure the hard disk.

  • Page 58: Advanced Cmos Setup Defaults

    ECB-862/862L 4.5.3 Advanced CMOS Setup Defaults This Setup includes all of the advanced features in the system. The detail descriptions are specified as below. Figure 3: The Advanced CMOS Features 4.5.3.1 Virus Warning Allows you to choose the VIRUS Warning feature for IDE Hard Disk boot sector protection. If this function is enabled and someone attempt to write data into this area, BIOS will show a warning message on screen and alarm beep.
  • Page 59 User’s Manual 4.5.3.2 CPU Internal Cache/External Cache These two categories speed up memory access. However, it depends on CPU/chipset design. Enabled Enable cache Disabled Disable cache 4.5.3.3 Quick Power On Self Test This category speeds up Power On Self Test (POST) after you power up the computer. If it is set to Enable, BIOS will shorten or skip some check items during POST.
  • Page 60 Once the security is disabled, the system will boot and you can enter Setup freely. 4.5.3.13 APIC Mode The BIOS supports versions 1.4 of the Intel multiprocessor specification. When enabled, The MPS Version 1.4 Control for OS can be activated. The choice: Enabled/Disabled. 4.5.3.14 OS Select for DRAM >...
  • Page 61 User’s Manual 4.5.3.15 Report No FDD for Win 95 While the FDD in “ STANDARD CMOS SETUP ” is set to NONE, set this option to No to release IRQ6 for passing Win95 logo. This option is irrelevant under normal operation. The choice: Yes, No.

  • Page 62: Advanced Chipset Setup Defaults

    ECB-862/862L 4.5.4 Advanced Chipset Setup Defaults This Setup is very important to keep system’s stability. If you are not technical person, do not attempt to change any parameters. The best way is to choose optimal default setting. Figure 4: The Advanced Chipset Features This section allows you to configure the system based on the specific features of the installed chipset.
  • Page 63 User’s Manual 4.5.4.1 DRAM Timing Selectable If your DIMM memory has SPD (Serial Presence Detect) 8-pin IC on module, you can set this option to “By SPD”. System will set your SDRAM clock and timing from the SPD IC. If the option set as ”Manual”, DRAM clock and timing must be set from items below: The choice: SPD, Manual.
  • Page 64 ECB-862/862L 4.5.4.8 System BIOS Cacheable Allows the system BIOS to be cached for faster system performance. The choice: Enable, Disable. 4.5.4.9 Video BIOS Cacheable Allows the video BIOS to be cached for faster video performance. The choice: Enable, Disable. 4.5.4.10 Video RAM Cacheable Allows the video RAM to be cached for faster video performance.

  • Page 65: Integrated Peripherals Setup Defaults

    User’s Manual 4.5.5 Integrated Peripherals Setup Defaults This section describes I/O resources assignment for all of on-board peripheral devices. Figure 5: The Integrated Peripherals Features 4.5.5.1 On-Chip Primary/Secondary PCI IDE Select “Enabled” to activate each on-board IDE channel separately, Select “Disabled”, if you install an add-on IDE Control card.
  • Page 66 ECB-862/862L 4.5.5.4 USB Controller Select Enabled if your system contains a Universal Serial Bus (USB) controller. The choice: Enable, Disable. 4.5.5.5 USB Keyboard Support This item lets you enable or disable the USB keyboard driver within the onboard BIOS. The choice: Enable, Disable. 4.5.5.6 Init Display First Select “AGP”...
  • Page 67 User’s Manual 4.5.5.8 POWER ON Function This field allows you to use the keyboard to power-on the system. Use Table 3 to configure this function. Item Options Description When this option is selected, move the cursor to the "KB Power On Password" field and press <Enter>. Enter your Password Press Enter password.
  • Page 68 ECB-862/862L 4.5.5.13 IR Transmission Delay If this option is enabled, transmission of data will be slower. This is recommended when you encounter transmission problem with your device. The choice: Disable, Enable. 4.5.5.14 UR2 Duplex Mode Select to activate the Infrared transfer function. This default setting is “Half“. The choice: Full, Half.

  • Page 69: Power Management Setup Defaults

    User’s Manual 4.5.5.20 PWRON After PWR-Fail Select the option for the system action after an AC power failure. When power returns after an AC power failure, the system's power is off. You must press the Power button to power-on the system. When power returns after an AC power failure, the system will automatically power-on.
  • Page 70 ECB-862/862L 4.5.6.1 ACPI Function This item allows you to enable or disable the function of Advanced Configuration and Power Interface (ACPI) that offers improved power management. The choice: Disable, Enable. 4.5.6.2 ACPI Suspend Type This field is used to select the type of Suspend function. S1 (POS) Enables the Power On Suspend function.
  • Page 71 User’s Manual 4.5.6.7 Suspend Type System further shuts down all devices and all right select stop Grant or Power on suspend function. The choice: stop Grant , PowOn Suspend. 4.5.6.8 MODEM Use IRQ This item tells the Power Management BIOS which IRQ is assigned to the installed MODEM.
  • Page 72 ECB-862/862L Note: The computer cannot receive or transmit data until the computer and application are fully running. After the item is set as enabled, the system must enter to OS once before system is turned off. 4.5.6.15 Wake up on LAN This allows you to remotely power up your systems through your network by sending a wake-up frame or signal.

  • Page 73: Pnp/ Pci Setup Defaults

    User’s Manual 4.5.7 PnP/ PCI Setup Defaults This section describes configuring the PCI bus system. PCI (Peripheral Component Interconnect) is a system that allows I/O devices to operate at speeds nearing CPU’s when they communicate with own special components. All of options described in this section are important and technical and it is strongly recommended that only experienced users could make any changes to the default settings.
  • Page 74 ECB-862/862L 4.5.7.3 Resources Controlled By Default setting is “Auto (ESCD)”. This setting allows the BIOS to self detect setting and Plug-and-Play devices during start up. The user can select and configure IRQs under "Manual" mode. The choice: Auto (ESCD), Manual. 4.5.7.4 IRQ Resources These options specify the bus that the named interrupt request lines (IRQs) are used on.

  • Page 75: Pc Health Status Setup Defaults

    User’s Manual 4.5.8 PC Health Status Setup Defaults This setup describes current CPU surface temperature status detected from hardware monitor sensor. The status showed on screen will include: 4.5.8.1 CPU Warning Temperature Select to enable or disable the hardware monitor sensor and set the warning temperature. BIOS Setup Items Optimal Default Failsafe Default Other Options...
  • Page 76 4.5.9.4 CPU Clock Ratio The Ratio of some latest Intel Corporation fixes CPUs and VIA so the Ratio cannot be changed with the setting. If it did not fix by CPU manufacturer, it may be changed with the setting. Over specification operations are not recommended.

  • Page 77: Load Fail-Safe Defaults

    User’s Manual 4.5.9.5 Auto Detect PCI CLK If you have the EMI issue, set the option as Enabled, it keeps its interference under control. The choice: Disable, Enable. 4.5.9.6 Spread Spectrum Using the setting “ Enabled “, for EMI testing will increase the system stability. The default setting is “...

  • Page 78: Load Optimized Defaults

    ECB-862/862L Load Fail-Safe Defaults (Y/N)? N If you want to process, type <Y> and press <Enter>. The default settings will be loaded. 4.5.11 Load Optimized Defaults This feature loads optimized setting from the BIOS ROM. Use the default values as standard values for your system.

  • Page 79: Flash Bios Utility

    User’s Manual Flash BIOS Utility Utilize Award Flash BIOS programming utility to update on-board BIOS for the future new BIOS version. Please contact your technical window to get this utility if necessary. Note: Remark or delete any installed Memory Management Utility (such as HIMEM.SYS, EMM386.EXE, QEMM.EXE, …, etc.) in the CONFIG.SYS files before running Flash-programming utility.

  • Page 80: Driver Installation

    ECB-862/862L 5. Driver Installation Driver Installation for Ethernet Adapter 5.1.1 Windows 9x The best way to install the driver for the Ethernet controller is to use the plug and play system of Windows 9x. The following procedures illustrate how the installation can be done.
  • Page 81 User’s Manual • If the ‘ Network adapters ’ line is present, expand the line and remove the PCI Ethernet Adapter. This is done by selecting the line and clicking the ‘ Remove ’ button. Before removal of the adapter(s), your screen might look like this: •...
  • Page 82 ECB-862/862L 4. Click the ‘ Next ’ button to continue the driver installation. 5. Specify the location of network adapter and click ‘ Next ’ (see below). 6. Click the ‘ Next ’ button to install the network adapter driver. ECB-862/862L User’s Manual 71...
  • Page 83 User’s Manual 7. Click the ‘ Finish ’ button. 8. To complete the installation, reboot the computer by clicking the ‘ Yes ’ button in the window shown below. 9. Please follow the Procedure 1-8 to install another Ethernet Adapter. 10.

  • Page 84: Driver Installation For Display Adapter

    ECB-862/862L Driver Installation for Display Adapter 5.2.1 Windows 9x The following steps will install the display driver for the ‘VIA PLE133T ’ display controller. 1. Find the directory of the driver disk with VIA PLE133T VGA driver. Double click the icon ‘setup’...
  • Page 85 User’s Manual 3. Click the ‘ Next ’ to continue the driver install. If you want to stop the installation, click the ‘ Cancel ’ 4. To complete the display driver installation, reboot the computer by clicking the ‘ Finish ’ button in the window shown below.

  • Page 86: Windows 2000

    ECB-862/862L 5.2.2 Windows 2000 The following steps will install the display driver for the ‘VIA PLE133T ’ display controller. 1. Find the directory of the driver disk with VIA PLE133T VGA driver. Double click the icon ‘setup’ on the folder. This should start the driver setup process as shown below: 2.
  • Page 87 User’s Manual 3. Click the ‘ Next ’ to continue the driver install. If you want to stop the installation, click the ‘ Cancel ’ 4. Click the ‘ Yes ’ to continue the driver install. If you want to stop the installation, click the ‘...
  • Page 88 ECB-862/862L 5. To complete the display driver installation, reboot the computer by clicking the ‘ Finish ’ button in the window shown below. ECB-862/862L User’s Manual 77...

  • Page 89: Driver Installation For Usb2.0 Adapter

    User’s Manual Driver Installation for USB2.0 Adapter 5.3.1 Windows 9x The following steps will install the display driver for the VIA VT6202 USB2.0 controller. 1. Find the directory of the driver disk with VIA VT6202 USB2.0 driver. Double click the icon ‘setup’...
  • Page 90 ECB-862/862L 3. Click the ‘ Next ’ to continue the driver install. If you want to stop the installation, click the ‘ Cancel ’ 4. To complete the USB Adapter driver installation, reboot the computer by clicking the ‘ Finish ’ button in the window shown below. ECB-862/862L User’s Manual 79...

  • Page 91: Windows 2000

    User’s Manual 5.3.2 Windows 2000 The following steps will install the display driver for the VIA VT6202 USB2.0 controller. 1. Find the directory of the driver disk with VIA VT6202 USB2.0 driver. Double click the icon ‘setup’ on the folder. This should start the driver setup process as shown below: 2.
  • Page 92 ECB-862/862L 3. Click the ‘ Yes ’ to continue the driver install. If you want to stop the installation, click the ‘ No ’ 4. Click the ‘ Next ’ to continue the driver install. If you want to stop the installation, click the ‘...
  • Page 93 User’s Manual 5. Click the ‘ Yes ’ to continue the driver install. If you want to stop the installation, click the ‘ No ’ 6. To complete the USB Adapter driver installation, reboot the computer by clicking the ‘ Print to File ’ button in the window shown below. 82 ECB-862/862L User’s Manual...

  • Page 94: Driver Installation For Audio Adapter

    ECB-862/862L Driver Installation for Audio Adapter 5.4.1 Windows 9X The following steps will install the display driver for the VIA VT82C686B Audio controller. 1. Find the directory of the driver disk with VIA VT82C686B Audio driver. Double click the icon ‘setup’ on the folder. This should start the driver setup process as shown below: 2.
  • Page 95 User’s Manual 3. Click the ‘ Next ’ to continue the driver install. If you want to stop the installation, click the ‘ Cancel ’ 4. To complete the display driver installation, reboot the computer by clicking the ‘ Finish ’ button in the window shown below.

  • Page 96: Windows 2000

    ECB-862/862L 5.4.2 Windows 2000 The following steps will install the display driver for the VIA VT82C686B Audio controller. 1. Find the directory of the driver disk with VIA VT82C686B Audio driver. Double click the icon ‘setup’ on the folder. This should start the driver setup process as shown below: 2.
  • Page 97 User’s Manual 3. Click the ‘ Next ’ to continue the driver install. If you want to stop the installation, click the ‘ Cancel ’ 4. To complete the display driver installation, reboot the computer by clicking the ‘ Finish ’ button in the window shown below.

  • Page 98: Measurement Drawing

    ECB-862/862L 6. Measurement Drawing ECB-862/862L User’s Manual 87...

  • Page 99: Appendix A: Bios Revisions

    User’s Manual Appendix A: BIOS Revisions BIOS Rev. New Features Bugs/Problems Solved Known Problems 88 ECB-862/862L User’s Manual...

  • Page 100: Appendix B: System Resources

    ECB-862/862L Appendix B: System Resources Memory Map The following table indicates memory map of ECB-862. The address ranges specify the runtime code length. Address Range Description Note 00000000h-0009FFFFh System board extension for ACPI BIOS 000A0000h-000AFFFFh VIA Tech VT8361/VT8601 Graphics Controller 000B0000h-000BFFFFh VIA Tech VT8361/VT8601 Graphics Controller 000C0000h-000C7FFFh...

  • Page 101: I/O - Map

    User’s Manual I/O – Map Certain I/O addresses are subject to change during boot as PnP managers may relocate devices or functions. The addresses shown in the table are typical locations. I/O Port Description Note 0000h-000Fh Direct memory access controller 0010h-001Fh Motherboard resources 0020h-0021h...
  • Page 102 ECB-862/862L I/O Port Description Note VIA Bus Master PCI IDE Controller 03F6h-03F6h 03F7h-03F7h Standard Floppy Disk Controller 03F8h-03FFh Communications Port (COM1) 04D0h-04D1h Motherboard resources 0CF8h-0CFFh PCI bus 1000h-101Fh VIA Tech 3038 PCI to USB Universal Host Controller 4000h-407Fh PCI bus 4080h-40FFh PCI bus 5000h-500Fh...

  • Page 103: Interrupt Usage

    User’s Manual Interrupt Usage. The actual interrupt settings depend on the PnP handler, the table below indicates the typical settings. Interrupt Description Note System timer Standard 101/102-Key or Microsoft Natural PS/2 Keyboard Programmable interrupt controller Communications Port (COM2) Communications Port (COM1) ACPI IRQ Holder for PCI IRQ Steering VIA Tech 3038 PCI to USB Universal Host Controller VIA Tech VT8361/VT8601 Graphics Controller...

  • Page 104: Appendix C: Award Bios Post Messages

    ECB-862/862L Appendix C: AWARD BIOS POST Messages During the Power On Self-Test (POST), if the BIOS detects an error requiring you to do something to fix, it will either sound a beep code or display a message. If a message is displayed, it will be accompanied by: PRESS F1 TO CONTINUE, CTRL-ALT-ESC OR DEL TO ENTER SETUP POST Beep Currently there are two kinds of beep codes in BIOS.

  • Page 105: Display Switch Is Set Incorrectly

    User’s Manual Display Switch Is Set Incorrectly Display switch on the motherboard can be set to either monochrome or color. This indicates the switch is set to a different setting than indicated in Setup. Determine which setting is correct, and then either turn off the system and change the jumper, or enter Setup and change the VIDEO selection.

  • Page 106: Invalid Eisa Configuration Please Run Eisa Configuration Utility

    ECB-862/862L Invalid EISA Configuration Please Run EISA Configuration Utility The non-volatile memory containing EISA configuration information was programmed incorrectly or has become corrupt. Re-run EISA configuration utility to correctly program the memory. NOTE: When this error appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility.

  • Page 107: Press A Key To Reboot

    User’s Manual Press A Key To Reboot This will be displayed at the bottom screen when an error occurs that requires you to reboot. Press any key and the system will reboot. Press F1 To Disable NMI, F2 To Reboot When BIOS detects a Non-maskable Interrupt condition during boot, this will allow you to disable the NMI and continue to boot, or you can reboot the system with the NMI enabled.

  • Page 108: Wrong Board In Slot Please Run Eisa Configuration Utility

    ECB-862/862L Wrong Board In Slot Please Run EISA Configuration Utility The board ID does not match the ID stored in the EISA non-volatile memory. NOTE: When this error appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility.

  • Page 109: Appendix D: Award Bios Post Codes

    User’s Manual Appendix D: AWARD BIOS POST Codes POST Code (hex) Description Test CMOS R/W functionality. Early chipset initialization: -Disable shadow RAM -Disable L2 cache (socket 7 or below) -Program basic chipset registers Detect memory -Auto-detection of DRAM size, type and ECC. -Auto-detection of L2 cache (socket 7 or below) Expand compressed BIOS code to DRAM Call chipset hook to copy BIOS back to E000 &...
  • Page 110 Reserved Initial Early_Init_Onboard_Generator switch. Reserved Detect CPU information including brand, SMI type (Cyrix or Intel) and CPU level (586 or 686). Reserved Reserved Initial interrupts vector table. If no special specified, all H/W interrupts are directed to SPURIOUS_INT_HDLR & S/W interrupts to SPURIOUS_soft_HDLR.
  • Page 111 User’s Manual POST Code (hex) Description Reserved 1. Program CPU internal MTRR (P6 & PII) for 0-640K memory address. 2. Initialize the APIC for Pentium class CPU. 3. Program early chipset according to CMOS setup. Example: onboard IDE controller. 4. Measure CPU speed. 5.
  • Page 112 ECB-862/862L POST Code (hex) Description 1. Calculate total memory by testing the last double word of each 64K page. 2. Program writes allocation for AMD K5 CPU. Reserved Reserved Reserved Reserved 1. Program MTRR of M1 CPU 2. Initialize L2 cache for P6 class CPU & program CPU with proper cacheable range.
  • Page 113 User’s Manual POST Code (hex) Description Reserved Prepare memory size information for function call: INT 15h ax=E820h Reserved Turn on L2 cache Reserved Program chipset registers according to items described in Setup & Auto-configuration table. Reserved 1. Assign resources to all ISA PnP devices. 2.
  • Page 114 ECB-862/862L POST Code (hex) Description 1. Call chipset power management hook. 2. Recover the text fond used by EPA logo (not for full screen logo) 3. If password is set, ask for password. Save all data in stack back to CMOS Initialize ISA PnP boot devices 1.

Table of Contents
