- Page 1 ® Intel EP80579 Integrated ® Processor with Intel QuickAssist Technology Development Kit User’s Guide October 2008 Order Number: 320067- 002US Arrow.com. Downloaded from...
- Page 2 Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order. Copies of documents which have an order number and are referenced in this document, or other Intel literature, may be obtained by calling 1-800-548- 4725, or by visiting Intel’s Web...
-
Page 3: Table Of Contents
Feature List ................... 13 Package Components..................13 System I/O ...................... 14 ® 2.3.1 Intel EP80579 Development Board I/O ............ 14 2.3.2 Super I/O (SIO) ..................14 2.3.3 PEX 8508 PCI Express* Switch ..............14 2.3.4 Marvell* 88E1141 Quad Ethernet Transceiver..........15 System Memory .................... - Page 4 ® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology— Contents 4.10 Electrical Considerations ..................47 4.10.1 DC Loading ....................47 4.10.2 PCI Express Add-in Connector Considerations ..........47 4.10.3 Fan Connector Current Capability..............48 4.11 Thermal Considerations ..................48 Pre-boot Firmware ....................49 Introduction ......................49 Pre-boot Firmware Boot Flow................49...
- Page 5 DDR2 Memory Configuration..................15 Supported DIMM Slot Populations................16 Pre-boot Firmware Features ..................16 ® Intel EP80579 Development Kit Revision Identification and Color Scheme...... 17 Ordering Information....................19 Component and Connector Layout Description ............. 27 ® Intel EP80579 IA-32 core Frequency Selection ............29 SMBus Connectivity....................
- Page 6 SMBus Header Pinout....................43 SSP Header Pinout....................43 Tertiary UART Pinout....................44 ® Intel EP80579, PEX8508 and 88E1141JTAG Header Pinout ...........44 FPGA JTAG Header Pinout ..................44 GPIO Header Pinout ....................45 DC Loading Characteristics Mode ................47 Fan Connector Current Capability ................48 Pre-boot Firmware Setup Main Menu ................50 Pre-boot Firmware Setup Program Function Keys ............50...
- Page 7 ® ® Revision History—Intel EP80579 Integrated Processor with Intel QuickAssist Technology Revision History Date Revision Description August 2008 Initial release October 2008 Updated Section 6.1.13 and included new graphics in Sections 2, 3, 5, 6. § § Development Kit User’s Guide...
-
Page 8: Introduction
® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Introduction Introduction ® This document provides user guide information for the Intel EP80579 Integrated ® Processor with Intel QuickAssist Technology Development Kit. The document contains ® ® a high-level description of the Intel... -
Page 9: Related Documents
Table 1. Related Documents Document Title Document Number ® Intel EP80579 Integrated Processor Product Line Datasheet 320066-001 ® Intel EP80579 Integrated Processor Product Line Platform 320068-001 Design Guide Acronyms Table 2 describes acronyms that are used throughout this document. - Page 10 ® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Introduction Table 2. Acronym Table (Sheet 2 of 2) Acronym Description Super IO Controller SMBIOS System Management BIOS specification Serial Peripheral Interface Bus System on Chip UART Universal Asynchronous Receiver/Transmitter UHCI...
-
Page 11: Product Specification
EP80579 Integrated Processor with Intel QuickAssist Technology Product Specification Overview ® This chapter contains an overview of the Intel EP80579 Development Kit product ® specifications. See the Intel EP80579 Integrated Processor Product Line Platform Design Guide for implementation details. 2.1.1 Product Description and Board Architecture ®... -
Page 12: Block Diagram Of The Intel Ep80579 Development Board
® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Product Specification ® Figure 1. Block Diagram of the Intel EP80579 Development Board DIMM 0 Primary DIMM 1 Development Kit User’s Guide October 2008 Order Number: 320067-002US Arrow.com. Arrow.com. Arrow.com. Arrow.com. -
Page 13: Feature List
® Product Specification—Intel EP80579 Integrated Processor with Intel QuickAssist Technology 2.1.2 Feature List ® Table 3 summarizes the major features of the Intel EP80579 Development Board. Table 3. Feature List Feature Description Comments Form Factor 13.00 inches x 10.75 inches ®... -
Page 14: System I/O
® The Intel EP80579 Integrated Processor provides a x8 PCI Express interface that is configured as two independent x4 PCI Express interfaces. One of the x4 PCI Express interfaces is connected to a PEX 8508 PCI Express switch to provide support for four x1 PCI Express interfaces in x4 slots. -
Page 15: Marvell* 88E1141 Quad Ethernet Transceiver
88E1141 Quad Ethernet Transceiver to provide three GbE RJ45 ports over copper. ® Note: The Intel EP80579 Development Board does not support Wake On LAN (WOL), but the ® Intel EP80579 Integrated Processor does support WOL. System Memory ®... -
Page 16: Supported Dimm Slot Populations
1 Dual Rank Empty Populated Supported Operating Systems ® The Intel EP80579 Development Kit is validated with the following operating systems: • Red Hat Enterprise Linux* 5 • FreeBSD* 6.2 • Microsoft Windows* XP Embedded* SP2 ® Note: Operating systems are not distributed with the Intel EP80579 Development Board, kit, or processor. -
Page 17: Intel ® Ep80579 Development Board Overview
EP80579 Development Board Overview ® Table 7 Figure 2 identify the Intel EP80579 Development Board. ® Table 7. Intel EP80579 Development Kit Revision Identification and Color Scheme Board Solder Product GPIO 1 GPIO 0 Mask Color ® Intel EP80579 Development Board Black Development Kit User’s Guide... -
Page 18: Mezzanine Cards
Figure 2. Intel EP80579 Development Board Mezzanine Cards ® The Intel EP80579 Development Board supports two types of mezzanine cards: the ® Intel EPAVM80579 Analog Voice Mezzanine Card (4-port analog voice card) and the ® Intel EPTEM80579 Quad T1/E1 Mezzanine Card (quad T1/E1 card). -
Page 19: Power Supply
Product Specification—Intel EP80579 Integrated Processor with Intel QuickAssist Technology Figure 3. Mezzanine Cards Power Supply ® The Intel EP80579 Development Kit comes with a standard, off-the-shelf ATX12V power supply. 2.10 Ordering Information Table 8. Ordering Information Product Name Product Code ®... -
Page 20: System Overview
EP80579 Integrated Processor with Intel QuickAssist Technology—System Overview System Overview Power Distribution ® Figure 4 shows the power distribution for the Intel EP80579 Development Board. For details on power distribution logic, see the Schematics and bill of materials for the ® ® Intel... -
Page 21: Power Distribution Block Diagram
® ® System Overview—Intel EP80579 Integrated Processor with Intel QuickAssist Technology Figure 4. Power Distribution Block Diagram Development Kit User’s Guide October 2008 Order Number: 320067-002US Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. -
Page 22: Platform Clocking
® The Intel EP80579 Development Board uses one CK-410 clock synthesizer to generate the host differential pair clocks and the 100 MHz differential clock to the DB800. The DB800 then generates the 100 MHz differential pair clock for PCI Express devices. -
Page 23: Platform Reset
® ® System Overview—Intel EP80579 Integrated Processor with Intel QuickAssist Technology Platform Reset ® Figure 6 depicts the reset logic for the Intel EP80579 Development Board. Figure 6. Reset Diagram Development Kit User’s Guide October 2008 Order Number: 320067-002US Arrow.com. -
Page 24: Smbus
The Intel EP80579 Development Board provides system management communication through SMBus connectivity. The SMBus is implemented as a single bus with three ® repeaters used for voltage translation, fan out and isolation on the Intel EP80579 Development Board. Figure 7 shows the block diagram of the SMBus system on the ®... -
Page 25: Technical Reference
EP80579 Development Board components layout. Board Components Layout ® Figure 8 Figure 9 show the front view and back view of the Intel EP80579 Development Board. Figure 10 shows the external peripheral connectors. Table 9 identifies the components and connectors called out in... -
Page 26: Back View Of The Board Components
® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Technical Reference Figure 9. Back View of the Board Components Development Kit User’s Guide October 2008 Order Number: 320067-002US Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. -
Page 27: Side View Of The Board Connectors
® ® Technical Reference—Intel EP80579 Integrated Processor with Intel QuickAssist Technology Figure 10. Side View of the Board Connectors Table 9. Component and Connector Layout Description (Sheet 1 of 2) Call-out Component/Connector ® Intel EP80579 Integrated Processor PEX PCIe Switch Chip... -
Page 28: Ia-32 Core Frequency Selection
RJ-45 Ethernet port 2 SPI Flash IA-32 Core Frequency Selection ® The Intel EP80579 Integrated Processor Product Line is offered in SKUs with a ® 1200 MHz, 1066 MHz or 600 MHz IA-32 core frequency. The Intel EP80579 ® Development Board is designed to use the Intel... -
Page 29: Smbus Address
“Short 2-3” means to use a 2 pin jumper to shunt pins 2-3 together “Short 1-2-3” means to use a jumper to shunt pins 1-2-3 together SMBus Address ® Table 11 shows the SMBus device addresses on the Intel EP80579 Development Board. Table 11. SMBus Connectivity... -
Page 30: System Leds
EP80579 Integrated Processor with Intel QuickAssist Technology—Technical Reference System LEDs ® The Intel EP80579 Development Board provides LEDs as indicators for system signals and voltages, as provided in Table Figure 11 shows the location of the LEDs. System LEDs are lit when the signal or voltage is active. -
Page 31: Fixed I/O Map And Interrupts
General purpose LED for SIO Fixed I/O Map and Interrupts ® See the Intel EP80579 Integrated Processor Product Line Platform Design Guide for information about fixed I/O maps and interrupts. Jumper Block Figure 12 shows the location of the jumper blocks. -
Page 32: Jumper Block Locations
® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Technical Reference Figure 12. Jumper Block Locations B6603-03 Table 13. Jumper Block Descriptions (Sheet 1 of 3) Default Location Jumper Name Ref Des Description Position SKU and Voltage Selection: V_SEL J7F2... - Page 33 ® ® Technical Reference—Intel EP80579 Integrated Processor with Intel QuickAssist Technology Table 13. Jumper Block Descriptions (Sheet 2 of 3) Default Location Jumper Name Ref Des Description Position Intel Internal Test Only 1.3V override selection: Short = Force IA core voltage to 1.3V 1.3V Override...
-
Page 34: Spi And Fwh Boot Option Jumpers
® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Technical Reference Table 13. Jumper Block Descriptions (Sheet 3 of 3) Default Location Jumper Name Ref Des Description Position Reset CMOS: CMOS Clear J3J1 1-2 = Normal Section 5.11 2-3 = Clear CMOS... -
Page 35: Header Blocks
® Warning: Before applying power to the Intel EP80579 Integrated Processor, ensure that the ® headers are connected correctly. Improper configuration of the Intel EP80579 Development Board headers may result in board damage. Figure 14. Header Locations Table 14. -
Page 36: Connector/Header Pinout Information
3: GND Connector/Header Pinout Information 4.8.1 ITP-XDP Connector Pinout ® The Intel EP80579 Development Board provides a 60-pin ITP-XDP connector for system debugging purposes. For ITP-XDP pinout, refer to Table Table 15. ITP-XDP Connector (Sheet 1 of 2) Name Name... -
Page 37: Atx12V Power Connector Pinout
ATX12V Power Connector Pinout ® The Intel EP80579 Development Board comes with a 2x12 main power connector. This connector is compatible with a 2x10 power connector. The board supports the use of ATX12V power supplies with either 2x10 or 2x12 main power cables. -
Page 38: Leb Compactflash* Connector Pinout
LEB CompactFlash* Connector Pinout ® The Intel EP80579 Development Board utilizes the Local Expansion Bus interface that is connected to the CompactFlash connector and runs in True IDE mode. For more information, refer to CF+ and CompactFlash Specification Revision 4.0, 5/24/06 for the standard True IDE mode pinout. - Page 39 ® ® Technical Reference—Intel EP80579 Integrated Processor with Intel QuickAssist Technology Table 19. Standard Mezzanine Connector Pinout (Sheet 2 of 3) Name Name HSSn _GPIO_0 HSSn _GPIO_1 EX_DATA_5 EX_DATA_4 EX_DATA_7 EX_DATA_6 EX_DATA_9 EX_DATA_8 EX_DATA_11 EX_DATA_10 EX_DATA_13 EX_DATA_14 EX_DATA_15 EX_DATA_16 EX_ADDR_1...
-
Page 40: Expansion Mezzanine Connector
® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Technical Reference Table 19. Standard Mezzanine Connector Pinout (Sheet 3 of 3) Name Name HSS_JTAG_TDI RST_N HSS_JTAG_TDO HSS_TXFRAME_y HSS_JTAG_TMS HSS_TXCLK_y HSS_TXDATA_y HSS_TXDATA_x HSS_TXFRAME_x HSS_RXDATA_x HSS_RXFRAME_x HSS_TXCLK_x HSS_RXCLK_x HSS_RXCLK_y HSS_RXFRAME_y HSS_RXDATA_y 2.5V 2.5V... - Page 41 ® ® Technical Reference—Intel EP80579 Integrated Processor with Intel QuickAssist Technology Table 20. Expansion Mezzanine Connector (Sheet 2 of 3) Name Name EX_RDY_N_3 EX_RDY_N_1 EX_RDY_N_2 EX_RDY_N_0 EX_CLK_HSSn EX_BE_3_N EX_BE_2_N EX_BE_1_N EX_BE_0_N EX_BURST EX_CS_N_7 EX_CS_N_6 EX_CS_N_4 EX_CS_N_3 EX_CS_N_2 EX_CS_N_1 EX_CS_N_0 CLK_32_IN...
-
Page 42: Can Header Pinout
CAN Header Pinout ® Both Intel EP80579 Integrated Processor Controller Area Network (CAN) interface pins connect to two individual CAN transceivers. After conditioning by the transceiver, the CAN signals will go to two separate 10-pin headers. For the CAN connector pinout, Table Table 21. -
Page 43: Front Panel Header
QuickAssist Technology 4.8.7 Front Panel Header ® The Intel EP80579 Development Board has a 10-pin keyed header for the front panel connector. This section describes the functions of the front panel header. Table 23 shows the pinout. Table 23. Front Panel Header Pinout... -
Page 44: Ssp Header
4.8.10 SIO Tertiary (Third) UART Header ® The Intel EP80579 Development Board utilizes the SIO to provide a third UART and RS-232 connectivity. The UART is connected to a 2x5 header. The pinout is provided in Table Note: SIO Tertiary UART can utilize the CAN cable interface. -
Page 45: Gpio Header
The FPGA JTAG header is not a standard header. The manufacturer and part number are Molex and 87832-142077. 4.8.12 GPIO Header ® The Intel EP80579 Development Board provides a GPIO header that can access the nine GPIO pins listed in Table Table 29. GPIO Header Pinout Signal... -
Page 46: Form Factor Of Intel ® Ep80579 Development Board
® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Technical Reference ® Figure 15. Form Factor of Intel EP80579 Development Board Development Kit User’s Guide October 2008 Order Number: 320067-002US Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. -
Page 47: Electrical Considerations
DC loading characteristics of the Intel EP80579 Development Board. ® This data is based on DC analysis of all the active components within the Intel EP80579 Development Board that impact its power delivery subsystems. The analysis does not include PCI Express add-in cards. -
Page 48: Fan Connector Current Capability
The Intel EP80579 Development Board is included with a heatsink thermal solution that is to be installed on the EP80579 Processor. This thermal solution has been tested in an open air environment at room temperature and is sufficient for evaluation purposes. -
Page 49: Pre-Boot Firmware
Interface) Flash; the FWH or SPI Flash can be updated using a flash utility tool that is provided by Intel or by using a floppy drive connected to the floppy header. The Pre-boot Firmware setup menu can be used to view and modify the system settings ®... -
Page 50: Serial Console Redirection
The Pre-boot Firmware supports redirection of both video and keyboard via a serial port. When console redirection is enabled, the remote console terminal sends ® keystrokes to the Intel EP80579 Development Board Pre-boot Firmware and the Pre- boot Firmware redirects the video to the console terminal. ® As an option, the Intel EP80579 Development Board can be operated without keyboard or video and can run entirely via the remote serial console. -
Page 51: Default Settings
Pre-boot Firmware setup via a USB keyboard. Pre-boot Firmware Recovery and Updates ® The Intel EP80579 Development Board Pre-boot Firmware can be updated by using the Pre-boot Firmware programming tool software flash utility (flash programmer). The ® ®... -
Page 52: Updating Pre-Boot Firmware
Development Kit (AMI’s Aptio* Flash Update Utility — AFUEFI). ® Updated Pre-boot Firmware images for the Intel EP80579 Development Board may be made available by Intel. The current Pre-boot Firmware image is available from the download center. The instructions in Section 5.8.2 guide you through the process of updating the firmware image. -
Page 53: Boot Options
(Image on the board must be equal or later than TRXT053.ROM.) ® 3. Boot the Intel EP80579 Development Board to the EFI shell. If needed, change the boot setting in the BIOS Setup Selection to boot from the EFI shell (If the boot ®... -
Page 54: Booting Without Attached Devices
The Pre-boot Firmware includes security features that restrict access to the Pre-boot ® Firmware setup menu and to define who is allowed to boot the Intel EP80579 Development Board. A supervisor password and a user password can be set for the ®... -
Page 55: Clearing Cmos
Clearing CMOS ® The Intel EP80579 Development Board provides a feature to clear the CMOS clock and date setting. Clearing the CMOS does not restore the original default setting for the Pre-boot Firmware. Here are the steps to clear CMOS: ®... -
Page 56: Platform Setup
® The Intel EP80579 Development Board is shipped as an open system attached to an acrylic base. Some assembly is required. Standoffs are mounted on the acrylic base to provide flexibility in changing hardware configurations and peripherals, such as is necessary in a lab environment. -
Page 57: Safety
EP80579 Development Board is susceptible to ® electrostatic discharge, which may cause failure or unpredictable operation. The Intel EP80579 Development Board must be operated on a flame retardant surface because a chassis is not included with the platform. Caution: Connecting the wrong cable or reversing a cable may damage the board and may damage the device being connected. -
Page 58: Connecting The Sata Cables
Port 0 and ending with Port 1. See Figure 18 Figure 19 for the location of the SATA connectors. Note: Intel recommends connecting the boot drive to SATA Port 0. Figure 18. Connecting SATA Port 0 Development Kit User’s Guide October 2008 Order Number: 320067-002US Arrow.com. -
Page 59: Installing Memory
® ® Platform Setup—Intel EP80579 Integrated Processor with Intel QuickAssist Technology Figure 19. Close-up of Connection SATA Port 0 6.1.3 Installing Memory The reference kit includes one 1 GB DDR2-800 DIMM. Use the following procedure to install the DIMM: 1. Ensure the tabs on the slot are open or rotated outward from the slot. -
Page 60: Connecting The Processor Heatsink And Fan
Figure 21. Proper Installation of Heatsink ® 4. Plug the fan connector into the CPU FAN connector on the Intel EP80579 Development Board. Figure 22 shows the location of the CPU FAN connector. See Section 4.1... -
Page 61: Installing The Pci Express Video Card
® Warning: Do not apply power to the Intel EP80579 Development Board until the heatsink and fans are correctly installed. The processor fan must be connected to the CPU FAN connector, not to a chassis fan connector (AUX/AUX0/AUX1). Connecting the processor fan to a chassis fan connector may result in on-board component damage that may halt fan operation. -
Page 62: Connecting The Keyboard And Mouse
The mouse and keyboard are not supplied by Intel. Note: The serial redirection feature can be enabled to remotely access the board through a ® serial cable without attaching a keyboard or mouse to the Intel EP80579 Development Board. See Section 6.1.7 for more information. -
Page 63: Connecting The Can Interface Cables (Optional)
Figure 19 on page 59 for the SATA Port 0 and SATA Port 1 locations. Figure 26. Connecting Ethernet Cable Port 0 Note: The Ethernet cable is not supplied by Intel. Development Kit User’s Guide October 2008 Order Number: 320067-002US Arrow.com. Arrow.com. -
Page 64: Stand-Alone Target Platform
1. The board supports the use of ATX12V power supplies with either 2x10 or 2x12 main power cables. ® 2. Plug the main connector into the Intel EP80579 Development Board. Ensure that the plug clip lines up with the clip lock and the connector pins easily fit into their appropriate slots. -
Page 65: Powering Up The System
Ensure the steps in the previous sections were precisely followed before powering up the system. ® Use the following procedure to power up the Intel EP80579 Development Board: 1. Ensure that the processor heatsink and fan are installed according to the procedure Section 6.1.4. -
Page 66: Connecting Mezzanine Cards (Optional)
Development Board is used to perform functions for the Time Division Multiplexing (TDM) interface. ® Only certain SKUs may contain this feature. This feature must be enabled with Intel EP80579 Integrated Processor Product Line software. See the processor software documentation for more information. -
Page 67: Connecting The Mezzanine Cards (Optional)
® ® Platform Setup—Intel EP80579 Integrated Processor with Intel QuickAssist Technology Figure 29. Connecting the Mezzanine Cards (optional) § § Development Kit User’s Guide October 2008 Order Number: 320067-002US Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. -
Page 68: Error Messages And Beep Codes
Beep Codes Error Messages and Beep Codes Pre-boot Firmware Beep Codes ® The Intel EP80579 Development Board speaker provides audible error message (beep code) information during POST. Table 35 provides information about the beep codes: Table 35. Beep Code Types... -
Page 69: Socketed Intel ® Ep80579 Integrated Processor With Intel ® Quickassist Technology
The EP80579 Processor connects to the Intel EP80579 Development Board by a socket that allows the user to replace the processor with a different EP80579 Processor SKU. This section provides directions on how to insert and extract the processor. Caution: Carefully follow these directions, otherwise the processor and platform may be damaged. -
Page 70: Ep80579 Processor Location
® ® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Socketed Intel ® EP80579 Integrated Processor with Intel QuickAssist Technology Extraction and Insertion Figure 30. EP80579 Processor Location EP80579 processor Development Kit User’s Guide October 2008 Order Number: 320067-002US Arrow.com. -
Page 71: Advanced Interconnections 1088 Pos Pga-To-Bga Socket
® ® Socketed Intel EP80579 Integrated Processor with Intel QuickAssist Technology Extraction ® ® and Insertion Instructions—Intel EP80579 Integrated Processor with Intel QuickAssist Figure 31. Advanced Interconnections 1088 POS PGA-to-BGA Socket Alignment Features Socket alignment features include holes at three corners. -
Page 72: Advanced Interconnections 1088 Bga-To-Pga Interposer (Pin Side Facing Up)
® ® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Socketed Intel ® EP80579 Integrated Processor with Intel QuickAssist Technology Extraction and Insertion Figure 32. Advanced Interconnections 1088 BGA-to-PGA Interposer (pin side facing up) Extraction Tool Guide Slots (x8) Alignment Features Interposer alignment features include posts at three corners. -
Page 73: Extraction Instructions - Intel ® Ep80579 Development Board With Advanced Interconnects Interposer
® ® Socketed Intel EP80579 Integrated Processor with Intel QuickAssist Technology Extraction ® ® and Insertion Instructions—Intel EP80579 Integrated Processor with Intel QuickAssist ® Extraction Instructions — Intel EP80579 Development Board with Advanced Interconnects Interposer Steps Figures Disengage CPU heatsink/fan retention clips from board mounted anchor clips located at opposing corners of CPU location. - Page 74 ® ® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Socketed Intel ® EP80579 Integrated Processor with Intel QuickAssist Technology Extraction and Insertion Steps Figures Insert the extraction tool blades into the guide slots located on edges of interposer. Slide the blade edges of the tool towards the...
- Page 75 ® ® Socketed Intel EP80579 Integrated Processor with Intel QuickAssist Technology Extraction ® ® and Insertion Instructions—Intel EP80579 Integrated Processor with Intel QuickAssist Steps Figures Gently push the arm of the extraction tool until interposer pins continue to release from socket further.
- Page 76 ® ® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Socketed Intel ® EP80579 Integrated Processor with Intel QuickAssist Technology Extraction and Insertion Steps Figures (For Single-sided Extraction Tools - Continued from step 2) Insert the two extraction tool blades into the guide slots located on the edges of the interposer.
- Page 77 ® ® Socketed Intel EP80579 Integrated Processor with Intel QuickAssist Technology Extraction ® ® and Insertion Instructions—Intel EP80579 Integrated Processor with Intel QuickAssist Steps Figures Insert the extraction tools’ blades into the opposing guide slots located on edges of interposer. Slide the blade edges towards the...
-
Page 78: Insertion Instructions - Intel ® Ep80579 Development Board With Advanced Interconnects Interposer
® ® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Socketed Intel ® EP80579 Integrated Processor with Intel QuickAssist Technology Extraction and Insertion ® Insertion Instructions — Intel EP80579 Development Board with Advanced Interconnects Interposer Steps Figures The figures at the right shows the heatsink top and bottom view. - Page 79 ® ® Socketed Intel EP80579 Integrated Processor with Intel QuickAssist Technology Extraction ® ® and Insertion Instructions—Intel EP80579 Integrated Processor with Intel QuickAssist Steps Figures Inspect the bottom of the interposed part for bent pins. If any pins are damaged or bent, do not install the part.
- Page 80 EP80579 Integrated Processor with Intel QuickAssist Technology Extraction and Insertion Steps Figures ® While holding the back of the Intel EP80579 Development Board in the CPU area for support, press down on top of the CPU’s integrated heat spreader to engage the interposer pins with the socket holes.
- Page 81 ® ® Socketed Intel EP80579 Integrated Processor with Intel QuickAssist Technology Extraction ® ® and Insertion Instructions—Intel EP80579 Integrated Processor with Intel QuickAssist Steps Figures Hook one end of the heatsink clip to one of the anchors located near the corner of the CPU.
- Page 82 ® ® ® Intel EP80579 Integrated Processor with Intel QuickAssist Technology—Socketed Intel ® EP80579 Integrated Processor with Intel QuickAssist Technology Extraction and Insertion Development Kit User’s Guide October 2008 Order Number: 320067-002US Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
