- Page 1 ECM-APL Intel® Apollo lake processor 3.5 Micro Module User’s Manual Ed – 26 December 2019 Part No. E2047393003R...
- Page 2 We assume no responsibility or liability for the use of the described product(s), conveys no license or title under any patent, copyright, or masks work rights to these products, and makes no representations or warranties that 2 ECM-APL User’s Manual...
- Page 3 For the most frequently asked questions, you can easily find answers in your product documentation. These answers are normally a lot more detailed than the ones we can give over the phone. So please consult the user’s manual first. ECM-APL User’s Manual...
- Page 4 A product returned without proof of the purchase date is not eligible for warranty service. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 4 ECM-APL User’s Manual...
-
Page 5: Table Of Contents
PC Buzzer header (JBZ1) ......................27 2.3.20 Battery connector (BT1) ......................28 2.3.21 Audio connector (JAUDIO1) ...................... 28 Signal Description – Audio connector (JAUDIO1) ..............28 2.3.21.1 3.BIOS Setup ........................29 Introduction ......................30 Starting Setup ......................30 ECM-APL User’s Manual... - Page 6 South Cluster Configuration ....................52 3.6.3.4.1 HD-Audio Configuration ...................... 53 3.6.3.4.2 PCI Express Configuration ....................53 3.6.3.4.2.1 PCI Express Root Port 3(i210/211) ..................54 3.6.3.4.2.2 PCI Express Root Port 4(i210/211) ..................55 3.6.3.4.2.3 PCI Express Root Port 5(mPCIe) ..................56 6 ECM-APL User’s Manual...
- Page 7 4. Drivers Installation....................... 65 Install Chipset Driver ....................66 Install TXE Driver ....................67 Install VGA Driver ....................68 Install Audio Driver (For Realtek ALC892) .............. 70 Install Ethernet Driver ....................71 5. Mechanical Drawing ....................73 ECM-APL User’s Manual...
-
Page 8: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x 3.5” ECM-APL Micro Module 1 x Cable set contains the followings: ... -
Page 9: Document Amendment History
User’s Manual 1.3 Document Amendment History Revision Date Comment December 2016 Initial Release March 2017 Add JLVDS1 and JBKL1 matching connector September 2019 Update System Specifications December 2019 Update System Specifications ECM-APL User’s Manual... -
Page 10: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up ECM-APL or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 11: System Specifications
User’s Manual 1.5 System Specifications System Onboard Intel® Pentium® /Celeron® /Atom ™ SoC BGA Processor (Apollo Lake Platform) BIOS AMI BIOS, 128 Mbit SPI Flash ROM System Chipset Apollo SoC integrated I/O Chip EC (ITE IT8528VG), E3900 Series CPU use EC (ITE IT8528VG I) for WT One 204-pin DDR3L SODIMM Socket, Supports 4G/8G &... - Page 12 ECM-APL User’s Manual 2 x Intel I211AT GbE controller LAN Chip (E3900 Series CPU use Intel I210IT for WT) Ethernet 10/100/1000 Base-Tx compatible Interface Internal I/O Connectors CPU_FAN1 4pin 2.5mm wafer header Buzzer With Pin header CMOS Battery CR2032 Power On...
-
Page 13: Architecture Overview-Block Diagram
User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of ECM-APL. ECM-APL User’s Manual 13... -
Page 14: Hardware Configuration
ECM-APL User’s Manual 2. Hardware Configuration 14 ECM-APL User’s Manual... -
Page 15: Product Overview
User’s Manual 2.1 Product Overview ECM-APL User’s Manual 15... -
Page 16: Jumper And Connector List
2 x 1 wafer, pitch 1.25 mm CPU fan connector 4 x 1 wafer, pitch 2.54 mm CPU_FAN1 Audio connector 6 x 2 header, pitch 2.00 mm JAUDIO1 LCD inverter connector 5 x 1 wafer, pitch 2.00 mm JBKL1 16 ECM-APL User’s Manual... - Page 17 2 x 1 wafer, pitch 2.00 mm SATA1 Serial ATA connector 1 HDMI connector HDMI1 BIOS SPI header 4 x 2 header, pitch 2.00 mm BIOS_SPI1 M.2 B key slot NGFF1 MINI_PCIE1 Mini-PCI connector SO_DIMM1 DDR3 SODIMM connector USIM1 Sim card slot ECM-APL User’s Manual 17...
-
Page 18: Setting Jumpers & Connectors
ECM-APL User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 AT/ ATX Input power select (JAT1) * Default 2.3.2 Serial port 1 pin9 signal select (JRI1) Ring* +12V * Default 18 ECM-APL User’s Manual... -
Page 19: Clear Cmos (Jbat1)
User’s Manual 2.3.3 Clear CMOS (JBAT1) Protect* Clear CMOS * Default 2.3.4 LCD backlight brightness adjustment (JBKL_SEL1) PWM Mode* DC Mode * Default ECM-APL User’s Manual 19... -
Page 20: Lcd Inverter Connector (Jbkl1)
ECM-APL User’s Manual 2.3.5 LCD Inverter connector (JBKL1) Signal +12V BKLEN VBRIGHT 2.3.6 CPU fan connector (CPU_FAN1) Signal +12V EC_TACH0 FAN_PWM0 20 ECM-APL User’s Manual... -
Page 21: Serial Port 2/3/4/5/6 Connector (Jcom2/3/4/5/6)
JCOM3 JCOM5 JCOM4 JCOM6 Signal PIN PIN Signal COM_DCD# COM_RXD COM_TXD COM_DTR# COM_DSR# COM_RTS# COM_CTS# COM_RI# 2.3.8 General purpose I/O connector (JDIO1) Signal PIN PIN Signal DIO_GP20 DIO_GP10 DIO_GP21 DIO_GP11 DIO_GP22 DIO_GP12 DIO_GP23 DIO_GP13 SMB_SCL_S0 SMB_SDA_S0 ECM-APL User’s Manual 21... -
Page 22: Touch Panel Connector (Jtouch1)
ECM-APL User’s Manual 2.3.9 Touch Panel connector (JTOUCH1) Signal THX+ THX- THPROBE_R THY+ THY- 2.3.10 SATA Power header (SATA_PWR1) Signal 22 ECM-APL User’s Manual... -
Page 23: Power Connector (Pwr1)
User’s Manual 2.3.11 Power connector (PWR1) Signal Signal +26V_VIN_VIN +26V_VIN_VIN 2.3.12 Low pin count interface (JLPC1) Signal PIN PIN Signal LPC_AD0 +3.3V LPC_AD1 PLT_RST_BUF# LPC_AD2 LPC_FRAME# LPC_AD3 LPC_PORT80_CLK LPC_SERIRQ ECM-APL User’s Manual 23... -
Page 24: Lvds Connector (Jlvds1)
LVDS_DATA0_P 10 LVDS_DATA1_P LVDS_DATA0_N 12 11 LVDS_DATA1_N LVDS_DATA2_P 16 15 LVDS_DATA3_P LVDS_DATA2_N 18 17 LVDS_DATA3_N LVDS_DATA4_P 22 21 LVDS_DATA5_P LVDS_DATA4_N 24 23 LVDS_DATA5_N LVDS_DATA6_P 28 27 LVDS_DATA7_P LVDS_DATA6_N 30 29 LVDS_DATA7_N LVDS_CLK1_P LVDS_CLK2_P LVDS_CLK1_N LVDS_CLK2_N +12V +12V 24 ECM-APL User’s Manual... -
Page 25: On-Board Header For Usb2.0 (Jusb1)
User’s Manual 2.3.14 On-board header for USB2.0 (JUSB1) Signal +5VSB USB_R_DN7 USB_R_DP7 2.3.15 EC Debug connector (JEC_ROM1) Signal EC_SMDAT_DEBUG EC_SMCLK_DEBUG ECM-APL User’s Manual 25... -
Page 26: Serial Port 1 In Rs-422/485 Mode (J422_485)
ECM-APL User’s Manual 2.3.16 Serial port 1 in RS-422/485 mode (J422_485) Signal PIN PIN Signal 485TX2- 485TX2+ 485RX2+ 485RX2- 2.3.17 Miscellaneous setting connector (JFP1) Signal PIN PIN Signal PWR_BTN_IN_EC# PMU_RSTBTN# FP_PWR_LED+ PWR_LED# HDD_LED# CASE_OPEN# 26 ECM-APL User’s Manual... -
Page 27: Bios Spi Header (Bios_Spi1)
User’s Manual 2.3.18 BIOS SPI header (BIOS_SPI1) Signal PIN PIN Signal +1.8VSB SPI_CS#0 CPI_CLK SPI_MISO SPI_MOSI SPI_HOLD# SPI_WP# 2.3.19 PC Buzzer header (JBZ1) Signal SOC_SPKR_R ECM-APL User’s Manual 27... -
Page 28: Battery Connector (Bt1)
HD_AGND HD_AGND LINE1-R-IN LINE1-L-IN MIC1-R-IN MIC1-L-IN FRONT-JD LINE1-JD MIC1-JD HD_AGND 2.3.21.1 Signal Description – Audio connector (JAUDIO1) Signal Signal Description LINE1-JD AUDIO IN (LINE_RIN/LIN)sense pin FRONT-JD AUDIO Out(ROUT/LOUT) sense pin MIC1-JD MIC IN (MIC_RIN/LIN) sense pin 28 ECM-APL User’s Manual... -
Page 29: Bios Setup
User’s Manual 3.BIOS Setup ECM-APL User’s Manual 29... -
Page 30: Introduction
If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. 30 ECM-APL User’s Manual... -
Page 31: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. ECM-APL User’s Manual 31... -
Page 32: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 32 ECM-APL User’s Manual... -
Page 33: Bios Setup
<Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. ECM-APL User’s Manual 33... -
Page 34: System Language
Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 34 ECM-APL User’s Manual... -
Page 35: Trusted Computing
3.6.2.1 Trusted Computing Item Options Description Enables or Disables BIOS support for security Disable, device. O.S. will not show Security Device. TCG Security Device Support Enable[Default] EFI protocol and INT1A interface will not be available. 3.6.2.2 APCI Settings ECM-APL User’s Manual 35... - Page 36 Watch Dog Select WatchDog. 1 min 2 min 10 min 30 min Disabled Enabled/Disabled USB Standby Power USB Standby Power Setting Enabled[Default] during S3/S4/S5. Disabled Wake Up By Ring Wake Up by Ring from S3/S4/S5. Enabled[Default] 36 ECM-APL User’s Manual...
-
Page 37: It8528 Super Io Configuration
Set Parameters of Serial Port 3 (COMC). Serial Port 4 Configuration Set Parameters of Serial Port 4 (COMD). Serial Port 5 Configuration Set Parameters of Serial Port 5 (COME). Serial Port 6 Configuration Set Parameters of Serial Port 6 (COMF). ECM-APL User’s Manual 37... -
Page 38: Serial Port 1 Configuration
3.6.2.3.1 Serial Port 1 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default] UART 232[Default] UART 232 422 485 UART 422 Change the Serial Port as RS232/422/485. UART 485 3.6.2.3.2 Serial Port 2 Configuration 38 ECM-APL User’s Manual... -
Page 39: Serial Port 3 Configuration
Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default] 3.6.2.3.3 Serial Port 3 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default] 3.6.2.3.4 Serial Port 4 Configuration ECM-APL User’s Manual 39... -
Page 40: Serial Port 5 Configuration
Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default] 3.6.2.3.5 Serial Port 5 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default] 3.6.2.3.6 Serial Port 6 Configuration 40 ECM-APL User’s Manual... -
Page 41: H/W Monitor
User’s Manual Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default] 3.6.2.4 H/W Monitor Item Options Description Enabled, Smart Fan Function Enables or Disables Smart Fan. Disabled[Default] 3.6.2.5 S5 RTC Wake Settings ECM-APL User’s Manual 41... -
Page 42: Serial Port Console Redirection
Select Dynamic Time, System will wake on the current time Dynamic Time + Increase minute(s). 3.6.2.6 Serial Port Console Redirection Item Options Description Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled 3.6.2.6.1 Legacy Console Redirection Settings 42 ECM-APL User’s Manual... -
Page 43: Cpu Configuration
Disabled[Default] VT-d Enable/Disable CPU VT-d. Enabled When a processor thermal sensor trips (either core), the PROCHOT# will be Disabled Bi-directional PROCHOT driven. If bi-direction is enabled, external Enabled[Default] agents can drive PROCHOT# to throttle the processor. ECM-APL User’s Manual 43... -
Page 44: Socket 0 Cpu Information
ECM-APL User’s Manual Disabled Thermal Monitor Enable/Disable Thermal Monitor. Enabled[Default] Disabled Monitor Mwait Enabled Enable/Disable Monitor Mwait. Auto[Default] HW_ALL[Default] P-STATE Coordination SW_ALL Change P-STATE Coordination type. SW_ANY Disabled[Default] Enable/Disable Digital Thermal Sensor. Enabled 3.6.2.7.1 Socket 0 CPU Information 44 ECM-APL User’s Manual... -
Page 45: Cpu Power Management Configuration
This option controls the Max Core C State Max Core C State Core C7 that cores will support. Core C6 Core C1 Unlimited Disabled C-State Auto Demotion Configure C-State Auto Demotion. C1[Default] Disabled C-State Un-demotion Configure C-State Un-demotion. C1[Default] ECM-APL User’s Manual 45... -
Page 46: Network Stack Configuration
ECM-APL User’s Manual 3.6.2.8 Network Stack Configuration Item Options Description Disabled[Default] Network Stack Enable/Disable UEFI Network Stack. Enabled 3.6.2.9 CSM Configuration Item Options Description Disabled[Default] CSM Support Enable/Disable CSM Support. Enabled 46 ECM-APL User’s Manual... -
Page 47: Nvme Configuration
DISABLE option will keep USB Auto devices available only for EFI applications. This is a workaround for OSes without XHCI Disabled XHCI Hand-off hand-off support. The XHCI ownership change Enabled[Default] should be claimed by XHCI driver. ECM-APL User’s Manual 47... -
Page 48: Security Configuration
CD-ROM to a drive type. 3.6.2.12 Security Configuration Item Options Description Enabled TXE HMRFPO TXE HMRFPO. Disabled[Default] Enabled[Default] TXE EOP Message Send EOP Message Before Enter OS. Disabled 48 ECM-APL User’s Manual... -
Page 49: Chipset
User’s Manual 3.6.3 Chipset 3.6.3.1 North Bridge Item Option Description 2 GB[Default] 2.25 GB Max TOLUD Maximum Value of TOLUD. 2.5 GB 2.75 GB ECM-APL User’s Manual 49... -
Page 50: South Bridge
Above 4GB MMIO BIOS assignment Disabled[Default] disabled automatically when Aperture Size is set to 2048MB. 3.6.3.2 South Bridge Item Option Description Quiet Serial IRQ Mode Configure Serial IRQ Mode. Continuous[Default] Windows[Default] OS Selection Android Select the target OS. Intel Linux 50 ECM-APL User’s Manual... -
Page 51: Uncore Configuration
CH7511 EDID Panel Option 1920x1080 18/2 EDID Option. 1280x1024 24/2 1440x900 18/2 1600x1200 24/2 1366x768 24/1 1920x1080 24/2 1680x1050 24/2 LVDS Brightness Control Method. 1.BIOS BIOS[Default] Brightness Control Method 2.Brightness Button 3.Variable Resistor OS Driver 4.OS Driver. ECM-APL User’s Manual 51... -
Page 52: South Cluster Configuration
ECM-APL User’s Manual LVDS Back Light PWM Select LVDS back light PWM duty. 100%[Default] 200[Default] LVDS Back Light PWM Select LVDS back light PWM Frequency. Frequency 3.6.3.4 South Cluster Configuration 52 ECM-APL User’s Manual... -
Page 53: Hd-Audio Configuration
User’s Manual 3.6.3.4.1 HD-Audio Configuration Item Option Description Disable HD-Audio Support Enable/Disable HD-Audio Support. Enable[Default] 3.6.3.4.2 PCI Express Configuration ECM-APL User’s Manual 53... -
Page 54: Pci Express Root Port 3(I210/211)
Enable PCIe root port Disable: Disable PCIe root port. Disable[Default] PCI Express Active State Power ASPM Management settings. L0sL1 Auto Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] PCIe Speed Gen1 Configure PCIe Speed. Gen2 54 ECM-APL User’s Manual... -
Page 55: Pci Express Root Port 4(I210/211)
Enable PCIe root port Disable: Disable PCIe root port. Disable[Default] PCI Express Active State Power ASPM Management settings. L0sL1 Auto Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] PCIe Speed Gen1 Configure PCIe Speed. Gen2 ECM-APL User’s Manual 55... -
Page 56: Pci Express Root Port 5(Mpcie)
Enable PCIe root port Disable: Disable PCIe root port. Disable[Default] PCI Express Active State Power ASPM Management settings. L0sL1 Auto Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] PCIe Speed Gen1 Configure PCIe Speed. Gen2 56 ECM-APL User’s Manual... -
Page 57: Pci Express Root Port 6(M.2)
Enable PCIe root port Disable: Disable PCIe root port. Disable[Default] PCI Express Active State Power ASPM Management settings. L0sL1 Auto Disabled[Default] L1.1 L1 Substates PCI Express L1 Substates settings. L1.2 L1.1 & L1.2 Auto[Default] PCIe Speed Gen1 Configure PCIe Speed. Gen2 ECM-APL User’s Manual 57... -
Page 58: Sata Drivers
Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive. Disabled[Default] Enable/Disable SATA Port 0/1 DevSlp. SATA Port 0/1 DevSlp Enabled Board rework for LP needed before enable. 58 ECM-APL User’s Manual... -
Page 59: Usb Configuration
Enable/Disable XHCI Pre-Boot Driver support. Disable[Default] Once disabled, XHCI controller would be function Enable[Default] disabled, none of the USB devices are detectable xHCI Mode Disable and usable during boot and in OS. Do not disable it unless for debug purpose. ECM-APL User’s Manual 59... -
Page 60: Security
ECM-APL User’s Manual 3.6.4 Security Setup Administrator Password Set setup Administrator Password User Password Set User Password 60 ECM-APL User’s Manual... -
Page 61: Secure Boot
Secure Boot Mode – Custom_Standard, Set UEFI Secure Boot Mode to STANDARD mode Standard Secure Boot Customization or CUSTOM mode, this change is effect after Customized[Default] save. And after reset, the mode will return to STANDARD mode. ECM-APL User’s Manual 61... -
Page 62: Key Management
Provision factory default keys on next re-boot Provision Factory Defaults Enabled when System is in Setup Mode. 3.6.5 Boot Item Option Description Number of seconds to wait for setup activation Setup Prompt Timeout 1~ 65535 key. 65535(0xFFFF) means indefinite waiting. 62 ECM-APL User’s Manual... -
Page 63: Save And Exit
User’s Manual On[Default] Bootup NumLock State Select the Keyboard NumLock state Disabled[Default] Quiet Boot Enables or disables Quiet Boot option Enabled Boot Option #1 Set the system boot order. 3.6.6 Save and exit ECM-APL User’s Manual 63... -
Page 64: Save Changes And Reset
This option restores all BIOS settings to the factory default. This option is useful if the controller exhibits unpredictable behavior due to an incorrect or inappropriate BIOS setting. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices. 64 ECM-APL User’s Manual... -
Page 65: Drivers Installation
User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. ECM-APL User’s Manual 65... -
Page 66: Install Chipset Driver
Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Install. Step 4. Installing. Step1. Click Next. Step 5. Complete setup. Step 2. Click Accept. 66 ECM-APL User’s Manual... -
Page 67: Install Txe Driver
Continue to go on. Step 3. Click Next to continue installation. Step 4. Installing. Step1. Click Next to start installation. Step 2. Click Next. Step 5. Click Finish to complete setup. ECM-APL User’s Manual 67... -
Page 68: Install Vga Driver
Windows 10 operation system. Step 3. Click Next. Step 1. Click Next. Step 4. Click Next. Step 2. Step 5. Click Next. Click Yes to accept license agreement. 68 ECM-APL User’s Manual... - Page 69 User’s Manual Step 6. Click Finish to complete setup. ECM-APL User’s Manual 69...
-
Page 70: Install Audio Driver (For Realtek Alc892)
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Installing. Step 4. Click Finish to complete the setup. Step 1. Click Next to continue setup. Step 2. Click Next. 70 ECM-APL User’s Manual... -
Page 71: Install Ethernet Driver
Windows 10 operation system. Step 3. Click Next. Step 1. Click Install Drivers and Software. Step 4. Click Next. Step 2. Click Next to proceed. Step 5. Click Install. ECM-APL User’s Manual 71... - Page 72 ECM-APL User’s Manual Step 6. Click Next. Step 7. Click Finish to complete the setup. 72 ECM-APL User’s Manual...
-
Page 73: Mechanical Drawing
User’s Manual 5. Mechanical Drawing ECM-APL User’s Manual 73... - Page 74 ECM-APL User’s Manual Unit: mm 74 ECM-APL User’s Manual...
