Dxr2 Decoder
Card
DynamicXtended Resolution
K Picture Enhancement Technology
K Double scans to 60 fields per second
K Resolution enhancement up to 1280x1024 full screen
K Dynamic vertical and horizontal interpolation filters
Connections
K RCA jack S/PDIF Out (5.1 channel Dolby Digital (AC-3)
K JST audio output connector (downmix 5.1 channels to stereo)
K High density connector for:
- S-Video output
- Composite Video output
K DB-15 VGA Out
K DB-15 VGA In
Video Playback
K DVD 1.0, MPEG-2 and MPEG-1
K 30 frames per second (NTSC)
K Full screen/window display of up to 1280x1024
K Analog video overlay function
K Simultaneous TV and Computer Display
Audio Playback
K Dolby Digital (AC-3)
K Linear PCM
K MPEG Audio (Video-CD)
VGA Compatibility
K Support Windows resolution up to 1280x1024 at 24-bit color/pixel
* Dolby Digital (AC-3) 5.1 channel audio requires an amplifier or receiver with Dolby Digital
coaxial input.
*
ready, 5.1 channel (DVD) digital coded bit stream
*
audio)
Technical Specifications 28
