Step 3: Install the
Drive in Your
Computer
You may want to connect the
cables as described below before
you insert the drive into the bay.
Then, feed the cables through the
bay as you insert the drive.
Set the Master/Slave jumpers to
Master as shown in the figure on
page 2, unless you know that you
will be connecting to the Primary
IDE connector with the hard disk
drive.
1. Insert the PC-DVD drive into the drive bay
as shown.
2. Connect a PC power cable to the PC-DVD
drive. The computer's power supply is
usually located in a rear corner; several
power cables extend from the box with
connectors available for internal devices.
Power In
connector
Power cable
Installing PC-DVD Encore 7
