Accessories

The TV Out cable is
approximately 6 feet in length.
To extend the length, you will
need a female-to-female adapter,
available from Creative Labs
Customer Service, and an
additional S-Video cable with
male connectors at each end.
Your PC-DVD Encore includes:
Audio cable with dual connectors
PC-DVD audio cable
VGA loopback cable
TV out cable
IDE data cable
To audio card
Dual connector
audio cable
VGA loopback cable
connects your VGA card to
the Dxr2 decoder card.
S-Video plug
TV Out cable
connects your television
Composite
monitor to the Dxr2
video out plug
decoder card.
To Dxr2
To PC-DVD drive
decoder card or
audio card
PC-DVD audio cable
To Dxr2
decoder card
IDE data cable
connects the PC-DVD drive to the
motherboard or IDE interface card.
