Services; Ipmi - Lenovo ThinkServer TS430 User Manual

User Role
Operator
Administrator

Services

You can configure the web server parameters (such as, HTTP Port Number, HTTPS Port Number, and
Timeout) on a remote computer. By default, the timeout is 1800 seconds; 32 for the Max Sessions.
When you finish the configuration, click Apply Changes.

IPMI

This screen contains two sections: IPMI Serial and IPMI Settings.
IPMI Serial
There are three serial configuration in IPMI Serial: Connection Mode Settings, Baud Rate, Flow Control and
Channel Privilege Level Limit.
Option
Connection Mode Settings
Baud Rate
Flow Control
Channel Privilege Level Limit
IPMI Settings
IPMI Settings provides remote configuration over LAN. To activate IPMI remote configuration by LAN, check
Enable IPMI Over LAN option, define the Channel Privilege Level Limit, and enter the Encryption Key.
When you finish the configuration, click Apply Changes.
Option
Enable IPMI Over LAN
Channel Privilege Level Limit
Encryption Key
Description
All BMC commands are allowed, except for configuration
commands that can change the behavior of the out-of
band interfaces. For example, Operator privilege does
not allow the capability to disable individual channels, or
change user access privileges.
All BMC commands are allowed, including configuration
commands. An Administrator can even execute
configuration commands that would disable the channel
that the Administrator is communicating over.
Description
Sets the IPMI serial connection mode from a drop-down
list. Options are Direct Connection Basic Mode and Direct
Connection Terminal Mode.
Sets the IPMI serial baud rate (data speed) from a
drop-down list. Options are 9600 bps, 19.2 kbps, 38.4
kbps, 57.6 kbps and 115.2 kbps.
Sets the Flow control value from a drop-down list.
Available values are None and RTS/CTS Flow control.
Sets the Channel privilege level from a drop-down list.
Available levels are Administrator, Operator and User.
Description
Enables IPMI Over LAN when the checkbox is checked.
Sets the maximum privilege level that can be accepted on
the LAN channel (Administrator, Operator or User).
Sets the Encryption Key. This field allows from 0 to 20
two-digit Hex characters and no spaces.
.
Chapter 6 ThinkServer Remote Management Module Web Console Options
15
