Dell FORCE10 Open Automation Configuration page 47

Command Syntax
package install {flash://filename |
ftp://userid:password@host-ipaddress/dir-path | tftp://
host-ipaddress/dir-path}
Where:
• flash://filename installs the VSN file stored in flash
memory on the switch.
• ftp://userid:password@host-ipaddress/filepath logs
in and installs VSN from a file stored on an FTP
server.
• tftp://host-ipaddress/filepath installs VSN from a
file stored on a TFTP server.
Prerequisites:
- Smart Scripting is a prerequisite for using Virtual Server Networking. You must first
install the Smart Scripting package before you can run the VSN application (see
Installing Smart Scripting)
To install the VSN package:
1. On a PC or other network device, go to the Dell Force10 web portal at
https://www.force10networks.com/CSPortal20/Main/SupportMain.aspx. Click
Login, enter your user ID and password, and click the Login button.
2. On the Customer Support page, click the Software Center tab.
3. In the left-hand column, click Automation Software.
4. At the bottom of the Terms and Conditions page, click I agree.
5. On the Automation Software page, under Software, click the
VSNAGENT2.0.x.tar.gz
6. In the dialog box, select the path for the local flash on the switch or a directory
path on a network server where you want to download the
VSNAGENT2.0.x.tar.gz file.
7. When the download is complete, enter the
FTOS CLI on a switch to install the VSN package in the internal flash memory.
8. Enter the following command to configure the Perl script (VSNAgent.pl) used for
VSN operations on VMware hypervisors: script /usr/pkg/scripts/VSNAgent/
VMWare/VSNAgent.pl.
To follow the progress of a package installation (or removal), enter the
packages command.
file.
package install
Command Mode Task
EXEC Privilege Install the VSN package in the running
configuration of the switch from local
flash memory or a network server.
command from the
show
Virtual Server Networking | 47
