46 | Virtual Server Networking
Enter the show vlan
switch. As shown in
configured are displayed with a
ports marked with an
switch, the VLAN has no tag; the associated ports are displayed with an
Figure 5-2. Display VSN Hypervisor-learned VLANs: show vlan
FTOS(conf-hypervisor)#show config
!
Codes: * - Default VLAN, G - GVRP VLANs, R - Remote Port Mirroring VLANs,
P - Primary, C - Community, I - Isolated
Q: U - Untagged, T - Tagged
x - Dot1x untagged, X - Dot1x tagged
G - GVRP tagged, M - Vlan-stack, H - VSN tagged
i - Internal untagged, I - Internal tagged, v - VLT untagged, V - VLT
tagged
NUM Status
* 1 Active
G 4001 Active
G 4002 Active
4003 Active

Hypervisor-unaware VLANs

VSN cannot discover VLAN configurations from a hypervisor. If an application
requires a hypervisor-unaware VLAN, you must configure the VLAN manually.
User-configured VLANs are not removed when VSN retrieves and updates a network
configuration.

Installing VSN

VSN is installed as a separate Open Automation package, apart from the FTOS image
and the downloaded Smart Scripting package. When you install the VSN package,
VSN is loaded into FTOS.
Note: VSN is not supported in stacked configurations; it is only supported on
standalone switches.
You install the VSN package file in the same way as you install an FTOS release:
directly from local flash memory on a switch or from an external drive on a network
server. Because the installation takes time, it is performed in the background. When
the download is complete, a message is displayed on the console. The package
installation updates the running-configuration file.
You must manually configure the interfaces used to connect to hypervisors. Refer to
the FTOS Configuration Guide, Interfaces chapter for information on how to
configure a VLAN or physical interface.
command to display the VSN hypervisor-learned VLANs on the
Figure 5-2, VSN VLANs that have been automatically
G tag in the left-most column and are associated with
tag. If a VSN VLAN has been manually configured on the
H
Description Q Ports
U Te 0/0,15,25,27,29,42-43
U Te 11/35-36
H Te 0/35
H Te 0/35
H Te 0/35
T Te 0/15
tag.
H
