Displaying Frame Relay information

Since Frame Relay configuration for the serial interface is complex and requires many commands, it is helpful
to list the frame relay configuration on screen.
This procedure describes how to display the Frame Relay configuration settings for the serial interface.
Mode: Port serial
Step
1 node(prt-ser)[slot/port]#show framerelay Displays Frame Relay information.
Example: Displaying Frame Relay information
The following example shows the commands used to display Frame Relay configuration settings.
node>enable
node#configure
node(cfg)#show framerelay
Framerelay Configuration:
Port LMI-Type
----------------------------------------------------------
serial 0 0 0 ansi
PVC Configuration:
Port DLCI
--------------------------------------------------------------
serial 0 0 0 1
Frame Relay configuration task list
Command
Keepalive
10
State Fragment
open disabled
15 • Frame Relay configuration
Purpose
Fragmentation
disabled
Encaps Binding
rfc1490 wan@router
