SmartWare Software Configuration Guide

Used IP ports

Component
H.323
UDP 4864...5118 (even numbers)
UDP 4865...5119 (odd numbers)
SIP
UDP 4864...5118 (even numbers)
UDP 4865...5119 (odd numbers)
NAPT
Telnet
Webserver
DHCP
TFTP
Used IP ports
Port
UDP 1719
TCP 1720
UDP 5060
TCP 5060
TCP 8000-15999
TCP 23
TCP 80
UDP 67
UDP 68
UDP 69
E • Used IP ports & available voice codecs
Description
RAS for gatekeeper connection
Call signaling port for H.323 (adjustable)
Voice data (RTP)
Voice statistics (RTCP)
Call signaling port for SIP (configurable)
Call signaling port for SIP (configurable)
Voice data (RTP)
Voice statistics (RTCP)
NAPT port range
TCP server port
TCP server port
Source port DHCP Server
Source port DHCP Client
Control port of the TFTP Server (accessed by the
TFTP Client in the SmartNode)
654
