SmartWare Software Configuration Guide
its own IP interface. In addition to these PPPoE sessions, pure IP traffic can run concurrently over the same
Ethernet port. This is achieved by binding the Ethernet port directly to an IP interface.
PPP configuration task list
To configure PPP, perform the following tasks:
•

Creating an IP interface for PPP

• Configuring for IP address auto-configuration from PPP (see
• Creating a PPP subscriber (for authentication) (see
• Configuring a PPPoE session (see
• Configuring PPP over a HDLC Link
• Creating a PPP interface within the CS context (not currently available)
• Creating a PSTN interface for PPP dial-in/dial-out (not currently available)
• Creating a PPP profile (see
• Displaying PPP configuration information (see
• Debugging PPP (see

Creating an IP interface for PPP

An IP interface is required to link a PPP connection to the IP context. The IP interface must apply a network
address port translation (NAPT) if the PPP service provider only offers a single IP address and not an IP sub-
net, or if the IP addresses on the LAN shall be private and hidden behind a public IP address (see 11,
NAPT configuration" on page 130 for more information about NAPT).
This procedure describes how to create an IP interface for PPP
Mode: Context IP
Step
1 node(ctx-ip)[router]#interface name
2 node(if-ip)[name]#point-to-point

PPP configuration task list

page 317)
page 319)
page 323)
Command
page 315)
page 315)
page 322)
Creates the new interface name, which repre-
sents an IP interface.
Only defines what route is entered into the IP
routing table:
• point-to-point: A route to the IP address of
the PPP interface (assigned by the PPP peer)
is entered into the routing table.
no point-to-point: A route to the subnet
•
defined by IP address of the PPP interface
(assigned by the PPP peer) is entered into
the routing table. The class of the IP address
determines the size of the subset.
Recommendation: Use 'point-to-point' and spec-
ify a default route.
30 • PPP configuration
"NAT/
Purpose
313
