SmartWare Software Configuration Guide

Adding a transmit mapping table entry

The transmit mapping table defines the conversion of transmitting firmware-specific service class value into a
Layer 2 CoS to service class value. Each conversion is stored as a mapping table entry, so the transmitting map-
ping table consists of several mapping table entries.
This procedure describes how to add a transmit mapping table entry.
Mode: Configure
Step
1 node(cfg)#port ethernet slot port
2 node(prt-eth)[slot/port]#cos tx-map service class value as layer 2 class of
service value
Example: Adding a transmit mapping table entry
The following example shows how to add a transmit mapping table entry, which converts a service class value
of 4 into a layer 2 class of service value of 2 for the Ethernet port on slot 0 and port 0.
node(cfg)#port ethernet 0 0
node(prt-eth)[0/0]#cos tx-map 4 as 2

Closing an Ethernet port

An Ethernet port can be closed with the
interface that is bound to that port. All static routing entries that are using this interface change their state to
'invalid' and all dynamic routing entries will be removed from the route table manager.
This command can be used as soon as an encapsulation type is defined and the port was bound successful to an
IP interface.
This procedure describes how to disable the Ethernet port on slot and port.
Mode: Configure
Step Command
1 node(cfg)#port ethernet slot port
2 node(prt-eth)[slot/port]#shutdown Disables Ethernet port on slot and port
The no prefix causes to open the port with the interface to which it is bound.
Ethernet port configuration task list
Command
command. This command also disables and closes the IP
shutdown
Enters Ethernet port configuration mode for the interface on
slot and port
12 • Ethernet port configuration
Purpose
Enters Ethernet
port configura-
tion mode for
the interface on
slot and port.
Adds a transmit
mapping table
entry, which
converts a ser-
vice class value
into a layer 2
class of service.
Purpose
