SmartWare Software Configuration Guide

Introduction

This chapter provides a general overview of IP interfaces and describes the tasks involved in their configura-
tion.
An interface is a logical entity that provides higher-layer protocol and service information, such as Layer 3
addressing. Interfaces are configured as part of a context and are independent of physical ports and circuits.
The separation of the interface from the physical layer allows for many advanced features. For higher layer pro-
tocols to become active, a physical port or circuit must be bound to an interface. IP interfaces can be bound
physically to Ethernet, SDSL or Frame Relay ports according to the appropriate transport network layer.
IP interface configuration task list
To configure interfaces, perform the tasks in the following sections:
• Creating an IP interface (see
• Deleting an IP interface (see
• Setting the IP address and netmask (see
• ICMP message processing (see
• ICMP redirect messages (see
• Router advertisement broadcast message (see
• Defining the MTU of the interface (see
• Configuring an interface as a point-to-point link (see
• Displaying IP interface information (see
• Testing connections with the

Creating an IP interface

Interface names can be any arbitrary string. Use self-explanatory names for your interfaces, which reflect their usage.
Mode: Context IP
Step
1 node(ctx-ip)[router]#interface name Creates the new interface name, which represents an IP
2 node(if-ip)[name]#

Introduction

page 119)
page 120)
page
page 122)
page 122)
page
page
command (see
ping
Command
121)
page 122)
123)
page 124)
124)
page 125)
interface. This command also places you in interface
configuration mode for the interface just created.
You are now in the interface configuration mode, where
you can enter specific configuration parameters for the
IP interface name.
10 • IP interface configuration
Purpose
119
