SmartWare Software Configuration Guide
Mode: System
Step
1
node(sys)#clock-source hw-type slot port
node(sys)#clock-source index hw-type slot port
node(sys)#clock-source before index hw-type slot port Insert an entry before position 'index'
node(sys)#clock-source after index hw-type slot port
node(sys)#clock-source index up positions
node(sys)#clock-source index down positions

Debugging the clock source

To control the system behaviour at runtime, there exists a debug command with the options 'event' and 'error'.
If the user enables the 'event' command, he can follow the system's Clock Source Hunting algorithm, the out-
put informs about the occurrence of a clock source change. In addition exists a 'show' command that prints the
clock source configuration and marks the ports that are synchronized. Further, the port that has been chosen
by the system as the current clock source will also be displayed.
Mode: Operator execution
Step
1
node#[no] debug system-clock {event | error}
Mode: Operator execution
Step
1
node#show system-clock
node#show system-clock
Current clock source
====================
t1 0 2 0
Registered clock sources
========================
Name
e1 0 1 0
t1 0 2 0
bri 0 3 0
bri 0 3 1
bri 0 3 2
bri 0 3 3
internal
Configuring general CS settings
Command
Command
Command
Sync
X
X
31 • CS context overview
Purpose
Add an entry to the end of the list
Overwrite and entry at position 'index'
Insert an entry after position 'index'
Move entry at 'index' number of 'posi-
tions' up
Move entry at 'index' number of 'posi-
tions' down
Purpose
Enables/Disables the system clock moni-
tor
Purpose
Print system clock information
342
