SmartWare Software Configuration Guide
• Binding the interface to a context SIP gateway (see
• Configure a remote host (see
• Configure a local host (Optional) (see
• Using an alternate VoIP profile (Optional) (see
• Using an alternate SIP profile (Optional) (see
• Using an alternate Tone-Set profile (Optional) (see
• Configuring early call connect /disconnect (Optional) (see
• Configuring address translation (Optional) (see
• SIP REFER Transmission (& ISDN Explicit Call Transfer support) (Optional) (see
• AOC over SIP (Optional) (see
• Enable the session timer (Optional) (see
• Enable the SIP penalty-box feature (Optional) (see
• Initiating a new SIP session for redirected SIP calls (Optional) (see
• Configure the SIP hold method (Optional) (see

Binding the interface to a SIP gateway

Every SIP interface must be explicitly bound to a context SIP gateway. It defines the transport interfaces to be
used to send requests and also from where it expects to receive incoming calls.
Mode: Interface SIP
Step
1
[node](if-sip)[if-name]# [no] bind context
sip-gateway gw-name
Configure a remote host
The remote host parameter is used to build the host part of the To-Header-URI and the Request-URI. All calls
forwarded to the context SIP gateway through this SIP interface will be sent to that host unless an outbound
proxy has been configured for the outgoing Request-URI. In this case, all requests will be sent to the specified
proxy independent of the Request-URI. For details about proxy configuration, see Chapter 51,
vice" on page 602.
The remote host parameter may contain a Domain Name, a Full Qualified Domain Name or an IP Address. If
domain names are used, do not forget to configure the DNS client for address resolving. See Chapter 28,
"DNS configuration" on page 302 for more information.
An optional port number can be entered on this command. It specifies the destination port of the requests to
be sent. If no port has been defined, the default SIP signaling port 5060 will be taken.
SIP interface configuration task list
page 438)
page 439)
page
page
page
page 448)
page 449)
page
Command
39 • SIP interface configuration
page 438)
439)
440)
page 440)
page 441)
441)
page 449)
page 449)
450)
Binds the interface to a context SIP gateway.
The no form of the command removes an
existing binding.
Default: none
page 446)
Purpose
"Location Ser-
438
