Installation - Electrical

WARNING
Hazardous Voltage w/Capacitors!
Disconnect all electric power, including remote disconnects
before servicing. Follow proper lockout/tagout procedures to
ensure the power cannot be inadvertently energized. For variable
frequency drives or other energy storing components provided by
Trane or others, refer to the appropriate manufacturer's literature
for allowable waiting periods for discharge of capacitors. Verify
with an appropriate voltmeter that all capacitors have discharged.
Failure to disconnect power and discharge capacitors before
servicing could result in death or serious injury.
Note: For additional information regarding the safe discharge of
capacitors, see PROD-SVB06A-EN or PROD-SVB06A-FR
All wiring must comply with local codes and the National Electric Code.
Typical field wiring diagrams are shown in Section "Unit Wiring". Minimum
circuit ampacities and other unit electrical data are on the unit nameplate and
are shown in Table 16. See the unit order specifications for actual electrical
data. Specific electrical schematics and connection diagrams are shipped
with the unit.
CAUTION
Use Copper Conductors Only!
Unit terminals are not designed to accept other types of
conductors. Failure to use copper conductors may result in
equipment damage.
Do not allow conduit to interfere with other components, structural members
or equipment.
Control voltage (115V) wiring in conduit must be separate from conduit
carrying low voltage (<30V) wiring.
58 RLC-SVX07A-EN
