Accessories Guide
Fully supervised wireless accessories
for PowerMax systems

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fully supervised wireless accessories and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Visonic Fully supervised wireless accessories

Summary of Contents for Visonic Fully supervised wireless accessories

  • Page 1 Accessories Guide Fully supervised wireless accessories for PowerMax systems...

  • Page 2: Table Of Contents

    PowerMax10-G2 Accessories Guide TABLE OF CONTENTS 9.1 Battery Replacement ........13 KEYFOBS (KF-234 PG2) ..........2 9.2 Maintenance ............. 14 1. INTRODUCTION ............2 10. ADDITIONAL ADVICE .......... 14 2. SPECIFICATIONS............. 2 10.1 Routine Testing..........14 3. ENROLLMENT ............2 10.2 Tips to Enhance Your Protection From Fires .

  • Page 3: Keyfobs (Kf-234

    KF-234 PG2 KEYFOBS (KF-234 PG2) Wireless PowerG 2-Way Keyfob Operating power is obtained from an internal 3V Lithium 1. INTRODUCTION battery. KF-234 miniature 2. SPECIFICATIONS PowerG 4-button (6-function) keyfob, designed for use with the Frequency Band (MHz): Europe: 433, 868, USA: 915 PowerMax10-G2.

  • Page 4: Operation

    8. MISCELLANEOUS COMMENTS once. 8.1 Product Limitations 6. MAINTENANCE Visonic Ltd. wireless systems are very reliable and are 6.1 Replacing the Battery tested to high standards. However, due to their low A replacement 3V battery, CR-2032, is available from transmitting power and limited range (required by FCC and hardware and electrical supply stores.

  • Page 5: Motion Sensors (Next Pg2, Next-K9

    NEXT PG2, NEXT-K9 PG2 MOTION SENSORS (NEXT PG2, NEXT-K9 PG2) Wireless, PowerG, Digital PIR / Pet Immune PIR Detectors 1. INTRODUCTION ELECTRICAL Internal Battery: 3V Lithium battery, type CR-123A or NEXT NEXT-K9 2-way, equivalent. microprocessor-controlled, wireless digital PIR detectors. Note: For UL installations use Panasonic, Sanyo, GP or Varta The detectors features are as follows: only.

  • Page 6: Modify Device Settings

    NEXT PG2, NEXT-K9 PG2 4. MODIFY DEVICE SETTINGS This section describes how to configure the parameters of the PIR detector from the PowerMax10-G2 control panel. To Modify the PIR Detector Device Settings Refer to the PowerMax10-G2 Installer Guide and perform the procedure for Adding A Wireless Device (section 4.4.2), or, Modifying a Device (section 4.4.5).

  • Page 7: Local Diagnostics Test

    NEXT PG2, NEXT-K9 PG2 5. LOCAL DIAGNOSTICS TEST 6. INSTALLATION 6.1 General Guidance (see fig. 4) Before testing, separate the base from the cover (see Fig. 5). A. Press the front tamper switch once and release it. 1. Keep away from heat 5.
  • Page 8 NEXT PG2, NEXT-K9 PG2 – Connect the device to an outlet on a circuit different from However, there is no guarantee that interference will not the one that supplies power to the receiver. occur in a particular installation. If this device does cause –...

  • Page 9: Smoke Sensors (Smd-426, Smd-427)

    SMD-426, SMD-427 SMOKE SENSORS (SMD-426, SMD-427) Supervised Wireless PowerG Smoke / Heat and Smoke Detector 1. DESCRIPTION AND APPLICATIONS ELECTRICAL DATA Power Source: 3 Volt CR123A / CR17450 lithium. SMD-426 (smoke detector) and SMD-427 (heat and Operation Voltage: From 2.7 V to 3 V. smoke detector) are automatic fire detectors with integral Current Drain: 18 µA standby, 70 mA max.

  • Page 10: Where To Install Smoke Detectors

    SMD-426, SMD-427 3.2 Where to Install Smoke Detectors • Be sure no door or other obstruction blocks the path of smoke to the detector. Smoke detectors should be installed in accordance with NFPA Standard (National Fire Protection • Install additional detectors in your living room, dining Association, Batterymarch Park, Quincy, MA 02169).

  • Page 11: Audible And Visual Indications

    SMD-426, SMD-427 • In close proximity to an automobile exhaust pipe; this will Table 1. Visual and Audible Indications damage the detector. Visual Indication (LEDs) Audio • In damp or very humid areas or near bathrooms with Condition Indication Yellow showers.

  • Page 12: Resetting The Transceiver Module

    SMD-426, SMD-427 Note: When the battery first makes contact, the alarm horn 3 volts CR17450 may sound for one second. This indicates that the battery is connected properly. Close the cover, then press the test button (see fig. 1) for about 2 seconds, (for further details see par.

  • Page 13: Smoke Detector Test

    SMD-426, SMD-427 The PowerMax10-G2 display will read [Fire Siren]. Fire Siren Press the button. The PowerMax10-G2 display will read [enable enable Press the button to select between "enable" and "disable", for example, "disable". disable Press to confirm the selection. disable The PowerMax10-G2 display will revert to [Fire Siren].

  • Page 14: Mounting

    SMD-426, SMD-427 D. At the end of the diagnostics test the LED blinks 3 D. Smoke detector may not be heard. The alarm horn in times. this smoke detector meets exceeds current The following table indicates received signal strength Underwriter’s Laboratories standards. However, if the indication.

  • Page 15: Maintenance

    SMD-426, SMD-427 10.2 Tips to Enhance Your Protection From Replace the battery as follows: Fires A. Separate the detector from its bracket (see figure 2). B. Replace battery (see Figure 3a or Figure 3b according Putting up smoke detectors is only one step in protecting to the battery used).

  • Page 16: More Tips On How To Face A Fire At Home

    SMD-426, SMD-427 11. STATEMENTS OF COMPLIANCE 10.3 More Tips on How to Face a Fire at Home The 315 MHz version of this device complies with Part 15 If you have made an escape plan and practiced it with your of the FCC Rules.

  • Page 17: Contact Sensors (Mc-302

    MC-302 PG2 CONTACT SENSORS (MC-302 PG2) Supervised PowerG Magnetic Contact Device 1. INTRODUCTION 3. INSTALLATION The MCT-302 PG2 is a fully supervised, PowerG magnetic 3.1 Mounting (Fig. 3a and 3b) contact device. The device includes a built-in reed switch It is highly recommended to attach the transmitter to the (that opens upon removal of a magnet placed near it).

  • Page 18: Enrollment

    7. MISCELLANEOUS COMMENTS C. Momentarily open the door or window and verify the red Visonic Ltd. wireless systems are very reliable and are LED blinks, indicating detection. tested to high standards. However, due to low transmitting D.
  • Page 19 The user is cautioned that changes or modifications to C. Wireless devices should be tested regularly to determine whether there are sources of interference the unit, not expressly approved by Visonic Ltd., could and to protect against faults. void the user’s FCC or other authority to operate the equipment.

  • Page 20: Repeaters (Rp-600

    RP-600 PG2 REPEATERS (RP-600 PG2) Wireless Repeater for PowerG Communications Current drain at 5.7 VDC 1. INTRODUCTION Frequency (MHz) The RP-600 PG2 is a range 100 mA 100 mA 100 mA extender designed to relay digital Battery Backup Duration (with fully charged 1300 mA/h data between wireless...

  • Page 21: Enrollment

    BATTERY Cover Closure 9. NOTES AND WARNINGS 9.1 Product Limitations Visonic Ltd. wireless systems are very reliable and are tested to high standards. However, due to their low transmitting power and limited range (required by FCC and CONNECT THE WIRES...
  • Page 22 RP-600 PG2 verified by turning the device off and on, the user is WARNING! Changes or modifications to this unit not encouraged to eliminate the interference by one or more of expressly approved by the party responsible for compliance the following measures: could void the user's authority to operate the equipment.

  • Page 23: Sirens (Sr-730

    (EVE • Strobe Light Color: The siren can be purchased with ER34615M/w200), Visonic assembly cat. No. 0-9912-K. red, blue, amber or transparent lens, according to the Note: The strobe flashes 5 times and the red LED lights desired strobe light color.

  • Page 24: Installation

    – Consult the dealer or an experienced radio/TV technician. Changes or modifications not expressly approved by Visonic Ltd. could void the user's authority to operate the equipment. 3. INSTALLATION tamper...

  • Page 25: Modify Device Settings

    SR-730 PG2 5. MODIFY DEVICE SETTINGS This section describes how to configure the parameters of the siren from the PowerMax10-G2 control panel. To Modify the Siren Device Settings Refer to the PowerMax10-G2 Installer Guide and perform the procedure for Adding A Wireless Device (section 4.4.2), or, Modifying a Device (section 4.4.5).
  • Page 26 SR-730 PG2 "Volume LOW" and "Volume MID", for example, "Volume LOW". Volume LOW Press to confirm the selection. Volume LOW The PowerMax10-G2 display will revert to [SOUNDER VOLUME]. SOUNDER VOLUME Press the button. The PowerMax10-G2 display will read [ACTIVITY LED]. ACTIVITY LED Press the button.

  • Page 27: Local Diagnostics Test

    SR-730 PG2 6. LOCAL DIAGNOSTICS TEST LED response Reception Green LED blinks Strong Before testing, remove the plastic cover and then open the Orange LED blinks Good battery cover (see Fig. 3). Red LED blinks Poor A. Press the self-test button once and release it; the following procedure should occur in turn: No blinks No communication...
  • Page 28 WARRANTY Visonic Limited (the “Manufacturer") warrants this product only (the "Product") to the original purchaser only (the However, if the Manufacturer is held liable, whether directly or indirectly, for any loss or damage arising under this “Purchaser”) against defective workmanship and materials under normal use of the Product for a period of twelve limited warranty, THE MANUFACTURER'S MAXIMUM LIABILITY (IF ANY) SHALL NOT IN ANY CASE (12) months from the date of shipment by the Manufacturer.
  • Page 29 VISONIC INC. (U.S.A.): 65 WEST DUDLEY TOWN ROAD, BLOOMFIELD CT. 06002-1376. PHONE: (860) 243-0833, (800) 223-0020. FAX: (860) 242-8094 VISONIC LTD. (UK): UNIT 6 MADINGLEY COURT CHIPPENHAM DRIVE KINGSTON MILTON KEYNES MK10 0BZ. TEL: (0870) 7300800 FAX: (0870) 7300801 PRODUCT SUPPORT: (0870) 7300830 VISONIC GMBH (D): KIRCHFELDSTR.
  • Page 30 Fully supervised wireless accessories Fully supervised less accessories Fully supervised wireless accessories Fully supervised wireless ssories Fully supervised wireless accessories Fully supervised wireless accessories supervised wireless accessories Fully supervised wireless accessories Fully rvised wireless accessories Fully supervised wireless accessories Fully supervised...
