P M
RINTER EMORY
One of the uses for printer memory is for temporarily storing
a print job while it is being processed. The more memory
installed in the printer, the more efficiently it can process one
or more print jobs.
Your SuperScript 1800 printer comes with 12MB of memory,
and can be upgraded to 132MB using 60ns, or faster, 72-pin
EDO DRAM SIMMs.
The printer has a Controller Board with two SIMM slots for
memory. The SIMM slots can be upgraded with 8MB, 16MB,
32MB, and 64MB SIMMs. If both slots are going to contain
SIMMs, they must be of the same size.
The 12MB of memory that comes with your printer is in the
form of 4MB built into the controller board and 8MB installed
in the SIMM slots.
Installing Printer Memory
A
2 slots for memory SIMMs
84 SuperScript 1800— User's Guide
U
PGRADE
B
Notch
To install a SIMM:
1. Remove the printer side cover and access the printer
controller board as described on page 83.
2. Position the printer so you have access to the controller
board.
3. Figure (A) shows the controller board and the location of
2 SIMM slots used for printer memory.
4. Locate the notch on the SIMM (B).
5. Position the SIMM into a slot so that the notch is at the
bottom (C).
6. Snap the SIMM into position (D).
7. Use the procedure in Step 1 as guide to replace printer
side cover, 500-sheet Cassette tray, and printer cables.
8. If your computer is running Windows 3.1x, 95, 98, or
NT 4.0, adjust the printer driver properties so the new
printer memory size is recognized. Typically, the
adjustment is made in the Device Options tab. The See
Chapter 4, "Printer Software," for more information.
9. Confirm the installation by printing a printer
configuration page as described on page 51.
C D
