Parallel Port
The IEEE 1284-compatible parallel port—used primarily for a printer—sends data in parallel
format.
13
25
Pin
Signal
1
STROBE_L
2
Data bit 0
3
Data bit 1
4
Data bit 2
5
Data bit 3
6
Data bit 4
7
Data bit 5
8
Data bit 6
9
Data bit 7
10
ACK_L (acknowledge)
11
BUSY
12
PE (paper end)
13
SLCT (select)
ICMB Connectors
The ICMB device provides external access to the ICMB devices that are within the chassis. This
makes it possible to externally access chassis management functions, alert logs, post-mortem data,
etc. The device also provides a mechanism for chassis power control. The server provides two
SEMCONN 6-pin connectors to allow daisy-chained cabling.
OM06193A
Pin
Signal
1
No connection
2
No connection
3
+ (positive)
4
- (negative)
5
No connection
6
No connection
214
1
14
OM00933A
Pin
Signal
14
AUFDXT_L (auto feed)
15
ERROR_L
16
INIT_L (initialize printer)
17
SLCTIN_L (select input)
18
GND (Ground)
19
GND
20
GND
21
GND
22
GND
23
GND
24
GND
25
GND
