Figure 10-1. Hard Disk Drive and Carrier
A.
EMI/ESD grounding clips and fingers
B.
SCA connector
C. SCSI hard disk drive
D. Drive carrier handle
Figure 10-2. Hard Disk Drive and Carrier Assembly
A.
Four screws
B
C
OM07153
OM08268
