Installing a SCSI SCA Hard Disk Drive in a Hot-docking Bay

See Figure 10-3.
1. Orient the carrier and drive assembly in front of the hot-docking bay guide rails so that metal
fingers of the perforated metal bracket attached to the carrier are facing up. Make sure that the
carrier is placed correctly into the guide rails to avoid damage.
2. While grasping only the drive carrier handle, firmly push the assembly into the bay until the
drive docks with the peripheral bay backplane connector.
CAUTION
Do not press on the perforated metal bracket of the carrier when you push
the assembly into the bay. Otherwise you may damage the metal fingers of
the bracket.
104
