3.
Secure the cover to the base unit with the screws retained earlier.
4.
Slide the base unit into the rack.
5.
Secure the base unit to the rack by replacing the screws attaching the handles to the rack.
6.
Reconnect all cables including the power cable, monitor, and peripheral cables to the back of
the system.
For the deskside configuration, reattach the face plate and follow steps 1, 2, 3, and 6 outlined
above. Return the chassis to the 90-degree deskside position.
System Illustrations
The following illustrations show both external and internal views of the system.
This front, right view shows the system with all covers in place .
Disk Drive Bay
With Door Lock
CD-ROM Drive
and System/Drive LEDs
Floppy Disk Drive
Power/Reset Keyswitch
5
