ABOUT ICONFIG
iConfig is an in-band utility created by IMC Networks, used for SNMP configuration
for IMC Networks' SNMP-manageable devices.
The iConfig feature allows you to perform the following:
•
Set an IP address, subnet mask and default gateway
•
Define community strings and SNMP traps
iConfig also includes an authorized IP address system and restricted access to MIB
groups which are supported by IMC Networks' manageable devices. These extra
layers of security do not affect SNMP compatibility. iConfig can upload new versions
of the system software and new MIB information. It also includes diagnostic
capabilities for faster resolution of technical support issues.
iConfig works with the following platforms:
•
Windows 98™
•
Windows NT™
•
Windows 2000™
•
Windows XP™
iConfig is also available as a standalone application. (Windows 98 users must use the
standalone version of iConfig.) Both applications are included on the iView² CD or
can be downloaded from the IMC website. For information regarding the use of
iConfig, refer to the iView² help menu.

About Features and Configuration

The IE-MiniFiberLinX-II offers a full feature set including Auto-Negotiation, Selective
Advertising, FiberAlert, AutoCross, read/write VLANs, SNMP management, bandwidth
control, and loopback testing. Features can be configured through software or via a
serial port, Telnet session, iConfig or SNMP.
Unit software updates can be downloaded through TFTP and iConfig.

LED Operation

The IE-MiniFiberLinX-II features two diagnostic LEDs:
•
FX LNK/ACT: This LED is on when a FX Link exists and blinks when data passes
through the fiber connection.
•
TX LNK/ACT: This LED is on when a TX Link exists and blinks when data passes
through the twisted-pair connection.
5
