These options include the following:
•
Host Displays the configuration screen for the Host connection.
•
Remote Displays the configuration screen for the Remote connection.
This will show the IE-MiniFiberLinX-II configuration information.
Information on this screen is provided on the following page.
The Host and Remote buttons will not appear when configuring the
IE-MiniFiberLinX-II alone. In this setup, a "Configuration" button will appear with
the same settings.
• Bandwidth - Displays the Bandwidth Limitation Settings.
• Port Desc - Displays a screen for setting port descriptions. Each name should not
exceed 32 characters or include any spaces.
• Tables - Displays a screen for viewing statistics tables regarding network
performance.
• Advanced - Displays the IE-MiniFiberLinX-II advanced settings.
• Agent Info - Information about the SNMP Management software is displayed here.
• Refresh - To refresh the iView² settings on any screen, click this button.
The Configuration/Remote Screen
Depending on whether the IE-MiniFiberLinX-II is being set up as a standalone or in a
Host/Remote connection, the Configuration or Remote buttons will show a screen for
configuring the IE-MiniFiberLinX-II settings.
NOTE
