Mode Three - Transparency with Tagged Management
This mode will pass all tagged and untagged customer traffic. Management traffic
must be tagged. It does not add or remove tags.
Select Y on the initial config screen. From the Transparent Mode Setup screen, select
Y and enter the Management Tag, as shown below.
Is a VLAN tag required on Management packets? [ Y ]
The Management Tag is
Management Priority is [4
Do you want to enter the Extra Tag mode? Enter Y for Extra Tagging.
Enter N if you do not want Extra Tags [ N ]
Mode Four - Transparency with Extra Tagging (or Q-in-Q)
This mode is designed to either pass all customer traffic with the defined extra tag (Q-
in-Q) or add and remove the defined extra tag (Q-in-Q) on all customer traffic.
Management traffic can be tagged or untagged.
Select Y on the initial config screen. Then, select Y when asked to select Extra Tags.
When setting this operation mode, the question "Are Extra Tags left on the Data Port"
should be answered NO for the remote IE-MiniFiberLinX-II and YES for the host
connection.
Is a VLAN tag required on Management packets? [ Y ]
The Management Tag is [111 ]
Management Priority is [4 ]
Do you want to enter the Extra Tag mode? Enter Y for Extra Tagging.
Enter N if you do not want Extra Tags [ Y ]
The Data Tag is [0 ]
Data Priority is [0 ]
Are Extra Tags left on the Data Port? [ N ]
Mode Five - VLAN Filter
This mode is designed to only pass traffic with any of the 32 tags that have been
identified in the user-defined table. No untagged traffic can pass and management
traffic must be tagged. No tags are added or removed from the traffic. Select N on
the initial config screen. Then, setup the VLAN screen, as shown in below.
TRANSPARENT MODE SETUP
[111 ]
]
TRANSPARENT MODE SETUP
