IMC Networks IE-MiniFiberLinX-II Operation Manual page 22

Unit FlowControl - This enables/disables Flow Control functionality on the unit and
must be enabled for Flow Control to function on any port.
Unit Control Settings
Serial/Telnet sessions display unit status as well as allowing configuration of some of
the IE-MiniFiberLinX-II features. Type unit and press Enter to be taken to the Unit
screen. From this screen, view the settings for Flow Control, FiberAlert, LoopBack,
Maximum Frame Size, and 802.1p Base Priority.
----------------- Unit Control Settings -------------------
Unit FlowControl
Unit FiberAlert
Unit LoopBack
Unit Max FrameSz
802.1p Base Pri
Use the arrow keys to navigate and the space bar to change the values on this screen.
These settings include:
Unit FlowControl
Unit FiberAlert
Unit LoopBack
Unit Max FrameSz
802.1p Base Pri
Disable FlowControl Globally
No FiberAlert or Linkloss Enabled
No LoopBack, Normal Traffic Mode
Oversized Frames:
Base Priority
Enable/Disable FlowControl.
Enable/Disable FiberAlert.
Enable/Disable the various LoopBack testing modes.
Set the maximum Frame Size to pass through the ports: 1518,
1522, 1536, or 1916.
Set the level of 802.1p base priority (3 or 4).
The IE-MiniFiberLinX-II has two outgoing queues; one for
high priority traffic and one for low priority traffic. If the Base
VLAN Priority is 4 for example, 0-3 are low priority and 4-7
are high priority. If the Base VLAN Priority is changed to 3, 0-
2 are low priority and 3-7 are high priority.
1916
4
