Enlarged version
VCX V7122/SIP Rear Panel with Two RJ-48c Connectors for Two Trunks
Figure 15
1
1610 Series
1
2
2
Ethernet
1
3
2
1
Figure 15 Legend
Table 9
1
cPCI Latch
2
Two E1/T-1 spans, RJ-48c trunk connectors
3
Two Ethernet Ports, RJ-45 LAN connectors
3Com VCX V7122/SIP VoIP Gateway User Manual
31
