Advanced Configuration
Figure 45
To display the active configuration of a section and its relevant parameters; click an
2
option in the sub-menu bar on the top (Network Settings or Channel Settings).
Network Settings
To set network settings, follow these steps:
On the sub-menu bar on the top, click Network Settings. The Network Settings screen
1
opens.
In the Network Settings screen, you can enter or modify the following information
2
IP settings, including the Gateway IP address and subnet mask
Logging settings, such as the IP address of the SysLog server. If the SysLog server
is disabled, the logging data is sent to the Gateway's serial RS-232 port
SNMP settings
RTP settings, including RTP base UDP port and IP TOS and Precedence QOS
parameters
Ethernet LAN Status (monitor only)
At the bottom of the screen, click Submit. The screen is refreshed.
3
