Figure 11 Legend
Table 5
1
cPCI Latch
2
FAIL (Red) – Board failure
ACT (Green) – Initialization OK
3
T1/E1 Status (for each of trunks 1 – 8)
Green -All OK
Red -Alarm due to any of these four:
LOS – Loss of Signal
LFA – Loss of Frame Alignment
AIS – Alarm Indication Signal
RAI – Remote Alarm Indication
4
Ethernet LEDs (for each line)
LINK – Green -Link all OK
ACT – Yellow Transmit/Receive
5
PWR (Green) – Power On
6
Swap Ready (Blue) –- cPCI Board can be removed
VCX V7122/SIP Rear Panels
The VCX V7122 is provided with several types of rear panels:
Rear panel with two 50-pin Telco connectors, shown in
up to 16 E1/T1 spans.
Rear panel with eight RJ-48c connectors, shown in
eight E1/T1 spans.
Rear panel with four RJ-48c connectors, shown in
four E1/T1 spans.
Rear panel with two RJ-48c connectors, shown in
two E1/T1 spans.
Rear panel with one RJ-48c connector, shown in
E1/T1 span.
3Com VCX V7122/SIP VoIP Gateway User Manual
Figure 12
on page 28, supporting
Table 6
on page 28, supporting up to
Table 7
on page 29, supporting up to
Table 8
on page 30, supporting up to
Table 9
on page 31, supporting one
27
