The procedure of defining the Call Progress Tones is described in
Tones".
For CAS signaling protocols, you also need to download one or more specific CAS.DAT files
according to the CAS signaling type you want to use. Several CAS.DAT files are provided in
the installation package.

Quick Setup Procedure

The 3Com VCX V7122/SIP Media Gateway is supplied with an integrated web server to be
used to configure the device and monitor it during run time.
This section describes how to set up the VCX V7122/SIP Media Gateway with basic
parameters, using a standard web browser such as Microsoft Internet Explorer (Version 5.0
and higher) or Netscape Navigator (Version 7.0 and higher) to access the web server.
It is assumed that the IP address of the Gateway is known. If the IP address is unknown, use
the 3Com Configuration Utility (or any standard BootP Server) to set the Gateway IP address
and subnet mask. The VCX V7122/SIP Gateways are shipped with the following network
parameters:
IP address of single module Gateway: 10.1.10.10
IP addresses of double module Gateway: 10.1.10.10 and 10.1.10.11
Subnet: 255.255.0.0
Default Gateway: 0.0.0.0
For a quick VCX V7122 setup, follow these steps:
Power-up the Gateway. After self-testing, in approximately 20 seconds the ACT LED on
1
front panel turns to green. Any malfunction causes the Fail LED to turn to red.
Change your PC's IP address and subnet mask to correspond with the Gateway's factory
2
default IP address and subnet mask.
Open any standard web-browsing application such as Microsoft Internet Explorer
3
(Version 5.0 and higher) or Netscape Navigator (Version 7.0 and higher) and specify the
IP address of the Media Gateway in the Address field (for example, http://10.1.10.10 for
the first module); the Embedded Web Server Enter Network Password screen
(Figure 17) appears.
38
"Using Call Progress
