VCX V7122/SIP Rear Panel with Four RJ-48c Connectors for Four Trunks
Figure 14
1
1610 Series
1
2
2
3
4
Ethernet
1
3
2
1
Figure 14 Legend
Table 8
1
cPCI Latch
2
Four E1/T-1 spans, RJ-48c trunk connectors
3
Two Ethernet Ports, RJ-45 LAN connectors
30
3Com VCX V7122/SIP VoIP Gateway User Manual
