TFTP Server IP – The IP of the TFTP Server.
Boot File, INI File – The files to request from the TFTP server.
Note that the seven check boxes to the right of the parameters. These enable you to assign
only the selected fields from the template. The rest can be unique for each client. When the
field is assigned a value from the selected template, the field is grayed out.
After performing changes, click Apply to save them. By clicking Apply & Reset, the program
saves the changes to the database, performs a remote reset to the client by adding the
client's MAC to the ARP table, and then sends out a reset command. This option works only
if ARP Manipulation Enabled check box in the Preferences window is checked (in
on page 151) otherwise an error message appears. It requires the user to have administrator
privileges. The remote reset is supported for software in this version and up.
When adding a new client, click the Add Client button; a client with blank parameters is
displayed. After filling out the parameters, click Apply; the client is added.
To find out if there is another BootP server on the net that contains a client with the same
MAC address, click Test Selected Clients; in the log screen, view the IP addresses of all
BootP servers that contain the same MAC address in the status Listed At. In normal
operation, BootP client MAC address should be listed only on a single BootP server. If the
MAC address is listed in multiple BootP servers, it must be removed from other BootP
servers.

Templates Window

Figure 65 shows the Templates window, which provides a fast way to configure a number of
clients that have the same parameters (except for the IP address). To use the Templates
window, create a template, and then apply the template to the client by selecting it.
