To access the Software Update menu, follow these steps:
To access the Software Update menu from the main menu list on the left, click Software
1
Update. The Software Update screen with the sub-menu bar on the top is displayed.
Software Update Menu
Figure 58
To display the active configuration of a section and its relevant parameters; click an
2
option in the sub-menu bar on the top (for example, TFTP Download or HTTP
Download).
TFTP Download
The TFTP Download screen facilitates the download of the image, *.CMP, and INI files using
the TFTP protocol.
To use the TFTP Download screen, follow these steps:
On the sub-menu bar on the top, click TFTP Download. The TFTP Download screen
1
opens.
TFTP Download Screen
Figure 59
Enter the relevant values in the fields and click Reset, a dialog box opens to confirm the
2
reset action; the server loads the ram.cmp, INI file and other configuration files (as
