SIP Configuration Parameters
Table 19
INI File Field Name
*
GUI Parameter Name
NumberMapTel2IP
(Manipulation Tables:
Tel IP Destination
Numbers)
NumberMapIP2Tel
(Manipulation Tables:
IP Tel Destination
Numbers)
SourceNumberMapTEL2IP
(Manipulation Tables:
Tel IP Source Numbers)
SourceNumberMapIP2TEL
(Manipulation Tables:
IP Tel Source Numbers)
AddTrunkGroupAsPrefix
(Add Trunk Group ID as
Prefix)
80
Valid Range and Description
a, b, c, d
a = Phone number prefix
b = Number of stripped digits
c = New prefix to be added, or none
d = Number of remained digits from right
The parameter defines set of rule(s) for changing the destination phone
number of incoming Tel
their telephone number correspond with the prefix a. The b, c, and d
actions apply to that number. The actions are executed in the following
order: b, d, and then c.
a, b, c, d, e, f
a = Phone number prefix
b = Number of stripped digits
c = New prefix to be added or none
d = Number of remained digits from right
e = H.225/Q.931 Number Plan
f = H.225/Q.931 Number Type
The parameter defines set of rule(s) for changing the destination phone
number of incoming Tel
their telephone number correspond with the prefix a. The b, c, and d
actions apply to that number. The actions are executed in the following
order: b, d, and then c.
Parameters can be skipped using the $$ sign, for instance:
NumberMapIP2TEL=01,2,972,$$,0,0
Same rules as for destination number.
Same rules as for destination number.
0 = not used
1 = For Tel IP incoming call, Trunk Group ID is added as a prefix to
destination phone number. Applicable only if Trunk group ID is defined.
Used to define various routing rules.
3Com VCX V7122/SIP VoIP Gateway User Manual
IP calls. Each set of rules applies to calls which
IP calls. Each set of rules applies to calls which
