Figure 3-3 CM401 Expansion Port: DB-25 Female pinout
Talkback to Mon A (SLS)
Talkback to Mon B (Cue 1)
Talkback to Mon C (Cue 2)
Talkback to Mon D (Cue 3)
13
25
Pin #
1 LED 1 output (active low)
2 Switch 1 input (active high)
3
4 LED 3 output (active low)
5 Switch 3 input (active high)
6
7 LED 5 output (active low)
8 Switch 5 input (active high)
9
10 LED 7 output (active low)
11 Switch 7 input (active high)
12
13
14
15 LED 2 output (active low)
16 Switch 2 input (active high)
17
18 LED 4 output (active low)
19 Switch 4 input (active high)
20
21 LED 6 output (active low)
22 Switch 6 input (active high)
23
24 LED 8 output (active low)
25 Switch 8 input (active high)
Table 3-1 Switch Functions
Function
Switch 1 (pin 2)
Switch 2 (pin 16)
Switch 3 (pin 5)
Switch 4 (pin 19)
+5 V (pins 3, 6, 14, 17)
Pin 1 Pin 15
TB to MON A TB to MON B
(SLS) (CUE 1)
Pin 2 Pin 16
Figure 3-4 Typical Talkback Wiring
1
14
Signal
+5V
+5V
+5V
+5V
+5V
+5V
+5V
+5V
+5V
Switch Talley
LED 1 (pin 1)
LED 2 (pin 15)
LED 3 (pin 4)
LED 4 (pin 18)
Pin 4 Pin 18
TB to MON C TB to MON D
(CUE 2) (CUE 3)
Pin 5 Pin 19
