Operating the VP-501xl/VP-502xl

You can operate your VP-501xl/VP-502xl via the front panel buttons,
which are dual-purpose buttons
•
Quick-set buttons: AUTO IMAGE, FREEZE and OS/US; or
•
Menu buttons: MENU, ENTER, – and +
This section describes how to:
•
Use the quick set buttons (see section 8.1)
•
Use the set of menu buttons (see section 8.2)
•
Use the Menu screen (see section 8.3)
•
Use the test patterns (see section 8.4)
•
Save and recall (see section 8.5)
•
Set the DIP-switches (see section 8.6)
1 Except for the MENU button
Operating the VP-501xl/VP-502xl

Figure 5: VP-502xl Alternate Connection
