Your VP-502xl

Figure 2 and
# Feature
1 12V DC
2 Y/C OUT 4-pin Connector
3 CV OUT BNC Connector
4 YUV, PAL DIP-switches
5 INPUT 15-pin HD Connector
6 OS LED
7 FREEZE. LED
8 MENU Button
9 ENTER / AUTO IMAGE
2
Button
10 - / FREEZE Button
11 + / OS/US Button
1 The displayed image, when set correctly, is larger than the screen
2 This button has dual functionality. When in the MENU mode, it functions according to the labeling above the button. When
not in the MENU mode, the labeling below the button takes precedence
3 The image is smaller than the screen, leaving a border around the image
4
Your VP-502xl
Table 2 describe the VP-502xl.

Figure 2: VP-502xl UXGA/HD Scan Converter

Table 2: VP-502xl Features

+12V DC connector for powering the unit
Connect to the s-Video acceptor
Connect to the composite video acceptor
Select the video standard (ON for PAL, OFF for NTSC) and the
color space (ON for YUV, OFF for RGB) (see section 8.6)
Connect to the computer graphics or HD source
Lights when the image is over-scanned
Lights When the FREEZE button is pressed
Press to enter the menu and adjust the Scan Converter features
Press ENTER to accept settings; press AUTO IMAGE to acquire
optimal screen display
Press - to scroll down the menu; press FREEZE to freeze video
image and features. Press again to disable
Press + to scroll up the menu; press OS/US to toggle between
over-scan3 and under-scan
Function
1
3
