8.2

Adjusting the Display via the Menu Buttons

The set of menu buttons (MENU, ENTER, − and +) let you adjust the
screen settings. Use the menu buttons as follows:
•
Press the MENU
•
Press the MENU button again each time you want to return to the
previous menu level or exit the menu
•
Press the + or - buttons to move up or down the menu respectively
•
Press ENTER to accept changes
•
Before exiting the menu, you can save settings
8.3

Using the Menu

Using the main menu, you can adjust the screen display
MENU button
buttons to scroll through the menu and make the required adjustments.
Table 3 defines the menu items.
Menu Items
Picture Setup Set the Contrast, Brightness, Sharpness and Saturation levels;
Set the Flicker Filter for flicker reduction
TV Output Setup Set the H Center, H Width, V Center and V Height levels
VGA Input Setup Set the VGA Left, VGA Width, VGA Top and VGA Bottom levels
Zoom Set the zoom to ON to zoom the image; when the zoom is selected, pan the H and V position
Advanced Select from seven different Test Patterns (for example, see
Select a test pattern to appear when no input is connected; and
Save up to 4 setups
Information Verifies the V Total Line, the H Timing, V Timing, and the software version
1 Pressing the MENU button disables the quick-set buttons (AUTO IMAGE, FREEZE and OS/US)
2 See section 8.5
3 Screen adjustments apply to both CV and Y/C displays
4 Quick set-buttons are disabled
5 The menu times-out after 20 seconds of inactivity
6 The flicker filter essentially blends the value of vertically adjacent pixels to decrease the differences in adjacent odd/even
lines. This dramatically reduces the noticeable image flicker, but equally as noticeably reduces the level of vertical detail as
compared to the original computer display.
7 To have a recalled setup appear after power cycling, you have to save that recalled setup once again before powering down
the unit, since the unit "remembers" the last setting that was saved
Operating the VP-501xl/VP-502xl
1
button to display the menu on the screen
4 5
, the main Menu

Table 3: VP-501xl/VP-502xl Menu Items

2
and recall
appears on the screen. Use the menu
Function
6
7
them
2
3
. After pressing the
Figure 7);
9
