Your VP-501xl

Figure 1 and
# Feature
1 12V DC
2 Y/C OUT 4-pin Connector Connect to the s-Video acceptor
3 CV OUT BNC Connector
4 PAL DIP-switch
5 INPUT 15-pin HD
Connector
6 OS LED
7 FREEZE. LED
8 MENU Button
9 ENTER / AUTO IMAGE
2
Button
2
10 - / FREEZE Button
2
11 + / OS/US Button
1 The displayed image, when set correctly, is larger than the screen
2 This button has dual functionality. When in the MENU mode, it functions according to the labeling above the button. When
not in the MENU mode, the labeling below the button takes precedence
3 The image is smaller than the screen, leaving a border around the image
Your VP-501xl
Table 1 describe the VP-501xl.

Figure 1: VP-501xl UXGA Scan Converter

Table 1: VP-501xl Features

+12V DC connector for powering the unit
Connect to the composite video acceptor
Select the video standard (ON for PAL, OFF for NTSC) (see section 8.6)
Connect to the computer graphics source
Lights when the image is over-scanned
Lights when the FREEZE button is pressed
Press to enter the menu and adjust the Scan Converter features
Press ENTER to accept the settings; press AUTO IMAGE to acquire optimal
screen display
Press - to scroll down the menu; press FREEZE to freeze the video image
and features. Press again to disable
Press + to scroll up the menu; press OS/US to toggle between over-scan
3
under-scan
Function
1
1
and
3
