FS-8704-06 BACnet IP Driver Manual
Page 6 of 57
3
HARDWARE CONNECTIONS
3
It is possible to connect a BACnet/IP device using the N1 or the N2
network ports. These ports need to be
configured for BACnet/IP in the configuration file.
Configure the Controller according to manufacturer's instructions
Remote BACnet IP
Device
Hub/Router
FieldServer Part #
8915-10
UTP cable
Connect to an Ethernet Port
on the FieldServer
8
1
FieldServer
N1
3
Not all ports shown are necessarily available on the hardware. Consult the appropriate Instruction manual for details of the ports available on
specific hardware.
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com
